NHTSA ID Number: 10163662
Manufacturer Communication Number: PIP5659
Summary
This Preliminary information communicates to the dealer technician that the tools to install the turbine shaft and stator shaft seals are available for loan from Bosch.
2 Affected Products
Vehicles
SEOCONTENT-START
Bulletin No.: PIP5659
Published date: 07/11/2019
Preliminary Information
PIP5659 2019 8L90 MQE Automatic Transmission Turbine And Stator Shaft Seal Installation Tools
Availability
Models
Brand: Model: Model Years:
VIN:
from to
Engine: Transmissions:
Chevrolet
Silverado 1500 (New Model) 2019 All All
All MQE GMC Sierra 1500 (New Model) 2019
All All All MQE
Involved Region or Country North America Additional Options (RPO) None
Condition
Technician’s may notice that during the installation of the front turbine shaft seals or the rear stator shaft seals for the 8L90 (MQE) automatic transmission the tools listed in SI
cannot be used.
Cause Changes have been made to the turbine shaft and the
stator shaft.
Correction:
Dealers may borrow the prototype turbine shaft and stator shaft tools by contacting Brian Echtinaw
at Bosch at 1- 800-468-6657.
The tools numbers needed are:
DT-50910-3A Turbine Shaft Seal Installer DT-50912-3A Stator Shaft Seal Installer
The production tools will be available for dealer purchase soon.
Version History
Version 1
Modified 07/11/2019 – Created on.
SEOCONTENT-END
