NHTSA ID Number: 10115111
Manufacturer Communication Number: PIC5458D
Summary
This Preliminary Information communication provides information to the technician about vehicles with water that may be leaking into the vehicle and accumulate in the rear floor pan area on either the left or right side of the vehicle. Technician will need to verify that the plastic water diverter that is sewn into the top is on the “wet-side” of the trim. Technician should also verify the front of the water management bag is properly attached to the body sheet metal panel then inspect the front drains for proper installation. Technician should also verify the presence and proper location of the foam tape on both the left and right side 5 bow brackets. Inspect the area of the vehicle where the folding top frame is fastened in place, if there is no visible seam sealer on the side of the vehicle that has the leak, this may be the cause for the concern.
Condition/Concern
Water may leak into the vehicle and accumulate in the rear floor pan area on either the left or right side of the vehicle. This could be caused by any of the following issues described below. Be sure to read over all possible areas of concern listed below.
Recommendation/Instructions
Note: When the water management bag has standing water in it (after a car wash, heavy rain, ice, etc.) you may hear a sloshing noise on acceleration, deceleration, cornering, or braking. This noise is normal and will go away after a few stops as the water makes its way to the drains.
Everything to the inboard side of the rear quarter glass is considered a dry area; water should not be in the “dry area” (1). Everything to the outboard side of the rear quarter glass is considered the “wet area” (2). It is acceptable and by design that water is present on the outboard side of the rear quarter glass and in the area of the quarter glass regulator that the front drain spills into.
Area of concern #1
The water diverter that is sewn into the canvas top may be on the “dry side” of the vehicle.
With the top in the closed and latched position, have an assistant stand outside of the vehicle and run water over the top of the car. While sitting in the back seat, lift the headliner up in the area behind the quarter window. With the water running, look past the headliner to confirm the water is draining into the water management bag. If the water doesn’t drain into the water management bag verify that the plastic water diverter (1) that is sewn into the top is on the “wet side” of the trim. The two pictures below show this plastic diverter in both the correct and incorrect positions.
Area of concern #2
Verify the front of the water management bag is properly attached to the body sheet metal panel. In the photo below, the water bag (1) is correctly positioned and attached to the vehicle’s sheet metal (2) in the LH photo. The RH photo shows the bag where it is not attached (2) to the sheet metal of the vehicle.
Area of concern #3
Inspect the front drains for proper installation. This can be difficult to confirm due to the limited space and limited visibility in this area. The following picture illustrates a drain that is not fully seated in position. The front drains are difficult to install and may not be fully seated in the body sheet metal panel. If the front drains were previously dislodged, it is possible that the drain may have taken set and will not remain in place. Replace the water management bag ONLY if the drain will not stay in place. Water management bag replacement can only be performed after removing the top from the vehicle.
Important: It is normal for the quarter glass window to make light contact with this drain when the window is rolled down. Modifications to the upper lip of the drain can be made if cycling the window results in the drain tube being pushed out of the sheet metal. An opening on the top of the drain tube that resembles th opening on the bottom of the tube can be made for this condition. The drain will not fall out of the body sheet metal unless the drain is not fully seated.
Area of concern #4
Verify the presence and proper location of the foam tape on both the left and right side 5 bow brackets, as shown in the following photograph.
By design, water runs along the folding top and down to the 5 bow and 5 bow brackets. It runs down until it hits the pieces of foam. Once it reaches this foam, it can no longer wick down the brackets and into the vehicle. Instead, the water drips off the brackets, directly into the water bag located directly below these foam pieces. If the foam pieces are damaged or missing, they will need to be replaced. If the foam pieces are still present, an additional layer of foam tape may be added on top of the existing foam pieces. This will make the foam stand taller, preventing water from overcoming the height of the foam. This peel-and-stick foam tape can be purchased at any local home improvement or hardware store.
Area of concern #5
Inspect the area of the vehicle where the folding top frame is fastened in place. There may be water leaking into the vehicle between 2 pieces of sheet metal in the quarter panel area. When comparing the body seams on both RH and LH sides of the vehicle, it may be noticed that there is visible seam sealer protruding from the body seams on only one side of the vehicle. If there is no visible seam sealer on the side of the vehicle that has the leak, this may be the cause for the concern. The first photograph below shows the area in question. The second photo shows a close up view of the circled area and the potential leak in the body seam. The LH side of the photo shows a body seam that has not been properly sealed. The RH side of the photo shows a body seam that has been properly sealed.
5 Affected Products
Vehicle
| MAKE | MODEL | YEAR |
| CHEVROLET | CAMARO | 2011-2015 |
1 Associated Document
Manufacturer Communications
Bulletin No.: PIC5458D
Date: Nov-2015
https://www.nhtsa.gov/recalls?nhtsaId=10115111
MC-10115111-9999.pdf 891.347KB
Loading...
Reload document
Open in new tab
NHTSA ID Number: 10075723
Manufacturer Communication Number: PIC5458D
Summary
Water may leak into the vehicle and accumulate in the rear floor pan area on either the left or right side of the vehicle. This could be caused by any of the following issues described below. Be sure to read over all possible areas of concern listed below.
1 Associated Document
Service Bulletin Document
Bulletin No.: PIC5458D
Date: 10-Nov-2015
https://www.nhtsa.gov/recalls?nhtsaId=10075723
SB-10075723-2280.pdf 324.183KB
Loading...
NHTSA ID Number: 10112669
Manufacturer Communication Number: PIC5458C
Summary
This Preliminary Information communication provides information to the technician about vehicles with water that may be leaking into the vehicle and accumulate in the rear floor pan area on either the left or right side of the vehicle. Technician will need to verify that the plastic water diverter that is sewn into the top is on the “wet-side” of the trim. Technician should also verify the front of the water management bag is properly attached to the body sheet metal panel then inspect the front drains for proper installation. Technician should also verify the presence and proper location of the foam tape on both the left and right side 5 bow brackets. Inspect the area of the vehicle where the folding top frame is fastened in place, if there is no visible seam sealer on the side of the vehicle that has the leak, this may be the cause for the concern.
1 Associated Document
Manufacturer Communications
Bulletin No.: PIC5458C
Date: Dec-2012
https://www.nhtsa.gov/recalls?nhtsaId=10112669
MC-10112669-9999.pdf 892.361KB
Loading...
NHTSA ID Number: 10071895
Manufacturer Communication Number: PIC5458C
Summary
SUMMARY TO BE PROVIDED ON A FUTURE DATE.
1 Associated Document
Manufacturer Communications
Bulletin No.: PIC5458C
Date: December, 2012
https://www.nhtsa.gov/recalls?nhtsaId=10071895
MC-10071895-3639.pdf 1594.772KB
Loading...
| “This site contains affiliate links for which OEMDTC may be compensated” |
- COMPLETE CARE FOR CONVERTIBLE TOPS - The Ultimate Convertible Top Care Kit offers everything needed to maintain the pristine condition of your convertible's soft top, regardless of its color or material.
- DEEP CLEANING ACTION - Chemical Guys Convertible Top Cleaner penetrates deep, effectively removing stubborn dirt, stains, and contaminants without harming the fabric or the car's finish.
- ADVANCED PROTECTION - The Convertible Top Protectant and Repellent provides a robust shield against liquids, dirt, UV rays, and stains, ensuring your top remains clean and vibrant for longer.
- ECO-FRIENDLY & SAFE - Designed without harsh chemicals or bleach, this cleaner is not only safe for your car but also environmentally friendly. It won't damage automotive finishes, chrome, or glass, making it the go-to choice for convertible top maintenance.
- THE GO TO BRAND IN CAR CARE - Car lovers choose Chemical Guys, not only for the finest car care products, but the world class customer support and vast detailing knowledge Chemical Guys is more than a brand it's a lifestyle with a worldwide following
- Keep your convertible top clean and looking like new with this specially formulated convertible top cleaner
- Safe and effective on all vinyl and fabric convertible tops
- Easily removes contaminants and stubborn stains like hard water, mildew, bird droppings and oil
- Penetrating formula safely removes stains with no hard scrubbing
- Convenient spray bottle makes for quick and easy use – simply spray on and wipe off for a gleaming, refreshed convertible top
- EXTRACT DIRT FROM SENSITIVE SOFT TOPS - The Convertible Top Brush uses soft, natural horse hair bristles to deep clean embedded dirt and tough stains to safely and gently restore the look of soft convertible tops.
- POWERFUL YET GENTLE - Cloth soft tops are sensitive to harsh chemicals, stiff bristle brushes, and improper cleaning techniques. The soft and durable horse hair bristles scrub cloth soft tops to agitate dirt, grease, and grime out from the fibers.
- RUGGED QUALITY THAT LASTS - The handle is contoured to the human hand for comfortable grip, powerful cleaning, and low fatigue with extended scrubbing.
- IDEAL FOR SENSITIVE SURFACES - The soft hairs scrub and break down stains and loosen dirt and grime, but are gentle enough to not damage any sensitive surfaces; leather, fabric, upholstery
- THE GO TO BRAND IN CAR CARE - Car lovers choose Chemical Guys, not only for the finest car care products, but the world class customer support and vast detailing knowledge Chemical Guys is more than a brand it's a lifestyle with a worldwide following
- Safely cleans and brightens both hard and soft tops
- Great for use on Tonneau Covers, fabric & vinyl convertible tops, and car bras
- Rinses residue free
- Made in the U.S.A.
- Cleans convertible tops and tonneau covers
- Safely removes dirt and stains
- Works on vinyl, fabric, canvas, textile, and synthetic soft tops
- Sprayable formula
- Works on all colors
- Fast cleaning, removes stubborn stains
- Hith Tech Fabric Guard restores oil & water repellency
- Protects against soiling & staining
- Adds years of life to tops
- Due to a recent formula issue, 303 Fabric Guard may cause a white residue on your fabric. The residue can be removed by using any fabric safe cleaner, dish soap or laundry soap. Please contact the manufacturer for a full refund if you experience this issue.
- Fast cleaning, removes stubborn stains
- Protectant restores original color-Protects against staining & sun damage
- Adds years of life to tops & covers-Fast cleaning, removes stubborn stains
- Protectant restores original color
- Protects against staining & sun damage
- Convertible tops bear the brunt of Mother Nature's worst: bird droppings, tree-sap, fallout, pollen, dirt, grime, and more.
- Maintains your top's factory appearance
- Leaves no residue to attract dust and dirt
- Removes contaminants from cloth and vinyl tops
- RaggTopp Premium Fabric Convertible Top Kit has all of the essential products you’ll need to clean and protect your fabric convertible top. Skip the guessing game of trying to decide the right products because RaggTopp, the leading company in convertible top care, has done it for you!
- Tested and Endorsed by HAARTZ
- Anti-Oxidant, Low pH, NO Bleach Formula, Leaves No Residue
- Will Not Harm Metal, Plastic, Rubber or Wood Finishes
- Safely Removes the Toughest Roof Soils and Some Stains
Last update on 2024-04-10 / Affiliate links / Images from Amazon Product Advertising API
This product presentation was made with AAWP plugin.
SEOCONTENT-START
Bulletin No.: PIC5458D
Date: Nov-2015
Subject: Water Leak In Rear Floor Area Models: 2011 – 2015 Chevrolet Camaro Convertible
This PI was superseded to update model years. Please discard PIC5458C.
The following diagnosis might be helpful if the vehicle exhibits the symptom(s) described in this PI. Condition/Concern
Water may leak into the vehicle and accumulate in the rear floor pan area on either the left or right side of the vehicle. This could be caused by any of the following issues described below. Be sure to read over all possible areas of concern listed below.
Recommendation/Instructions
Note: When the water management bag has standing water in it (after a car wash, heavy rain, ice, etc.) you may hear a sloshing noise on acceleration, deceleration, cornering, or braking. This noise is normal and will go away after a few stops as the water makes its way to the drains.
Everything to the inboard side of the rear quarter glass is considered a dry area; water should not be in the “dry area” (1). Everything to the outboard side of the rear quarter glass is considered the “wet area” (2). It is acceptable and by design that water is present on the outboard side of the rear quarter glass and in the area of the quarter glass regulator that the front drain spills into.
1 Area of concern #1
The water diverter that is sewn into the canvas top may be on the “dry side” of the vehicle.
With the top in the closed and latched position, have an assistant stand outside of the vehicle and run water over the top of the car. While sitting in the back seat, lift the headliner up in the area behind the quarter window. With the water running, look past the headliner to confirm the water is draining into the water management bag. If the water doesn’t drain into the water management bag verify that the plastic water diverter (1) that is sewn into the top is on the “wet side” of the trim. The two pictures below show this plastic diverter in both the correct and incorrect positions.
Correct Position Incorrect Position Area of concern #2 2 Verify the front of the water management bag is properly attached to the body sheet metal panel. In the photo below, the water bag (1) is correctly positioned and attached to the vehicle’s sheet metal (2) in the LH photo. The RH photo shows the bag where it is not attached (2) to the sheet metal of the vehicle. Area of concern #3
Inspect the front drains for proper installation. This can be difficult to confirm due to the limited space and limited visibility in this area. The following picture illustrates a drain that is not fully seated in position. The front drains are difficult to install and may not be fully seated in the body sheet metal panel. If the front drains were previously dislodged, it is possible that the drain may have taken set and will not remain in place. Replace the water management bag ONLY if the drain will not stay in place. Water management bag replacement can only be performed after removing the top from the vehicle. Important: It is normal for the quarter glass window to make light contact with this drain when the window is rolled down. Modifications to the upper lip of the drain can be made if cycling the window results in the drain tube being pushed out of the sheet metal. An opening on the top of the drain tube that resembles th opening on the bottom of the tube can be made for this condition. The drain will not fall out of the body sheet metal unless the drain is not fully seated.
Area of concern #4
Verify the presence and proper location of the foam tape on both the left and right side 5 bow brackets, as shown in the following photograph. 3 By design, water runs along the folding top and down to the 5 bow and 5 bow brackets. It runs down until it hits the pieces of foam. Once it reaches this foam, it can no longer wick down the brackets and into the vehicle. Instead, the water drips off the brackets, directly into the water bag located directly below these
foam pieces. If the foam pieces are damaged or missing, they will need to be replaced. If the foam pieces are still present, an additional layer of foam tape may be added on top of the existing foam pieces. This will make the foam stand taller, preventing water from overcoming the height of the foam. This peel-and-stick foam tape can be purchased at any local home improvement or hardware store.
Area of concern #5
Inspect the area of the vehicle where the folding top frame is fastened in place. There may be water leaking into the vehicle between 2 pieces of sheet metal in the quarter panel area. When comparing the body seams on both RH and LH sides of the vehicle, it may be noticed that there is visible seam sealer protruding from the body seams on only one side of the vehicle. If there is no visible seam sealer on the side of the vehicle that has the leak, this may be the cause for the concern. The first photograph below shows the area in question. The second photo shows a close up view of the circled area and the potential leak in the body seam. The LH side of the photo shows a body seam that has not been properly sealed. The RH side of the photo shows a body seam that has been properly sealed. 4 Warranty Information
The correction for this concern may be one of several repairs described above. For vehicles repaired under warranty, please use the appropriate warranty labor operation based on the actual cause and repair.
Please follow this diagnostic or repair process thoroughly and complete each step. If the condition exhibited is resolved without completing every step, the remaining steps do not need to be performed. GM bulletins are intended for use by professional technicians, NOT a “do-it-yourselfer”. They are written to inform these technicians of conditions that may occur on some vehicles, or to provide information that could assist in the proper service of a vehicle. Properly trained technicians have the equipment, tools, safety instructions, and know-how to do a job properly and safely. If a condition is described, DO NOT assume that the bulletin applies to your vehicle, or that your vehicle will have that condition. See your GM dealer for information on whether your vehicle may benefit from the information. WE SUPPORT VOLUNTARY TECHNICIAN CERTIFICATION
5
SEOCONTENT-END
