NHTSA ID Number: 10113795
Manufacturer Communication Number: PI1317A
Summary
This preliminary informational bulletin provides repair information to correct a customer concern that the rear liftgate will not open with the outside handle.
Condition/Concern
Some customers may comment that the rear liftgate will not open with the outside handle.
This may be due to the liftgate latch release cable becoming separated from the outside handle.
Note: Liftgate latch cable CLIPS are not serviced separately.
Recommendation/Instructions
Replace the liftgate latch release cable with a new designed cable and the liftgate latch handle which comes with a new design cable clip.
Follow the instructions listed below:
1. Remove the liftgate trim panel. Refer to Liftgate Trim Panel Replacement in SI.
Note: Notice the orientation of the cable for installation purposes.
2. Disconnect the cable from the outside handle.
3. Disconnect the cable from the liftgate latch.
4. Remove the liftgate handle. Refer to Liftgate Outside Handle Replacement in SI.
5. Install the cable to the latch and outside handle. Rotate the blue clip counterclockwise until the clip is fully engaged to the cable.
6. Install the liftgate trim panel. Refer to Liftgate Trim Panel Replacement in SI.
Parts
| CABLE ASM – L/GATE LAT | 94532037 |
| HANDLE, L/GATE O/S PULL | 94522304 |
3 Affected Products
Vehicles
3 Affected Products
Vehicles
1 Associated Document
Manufacturer Communications
Bulletin No.: PI1317A
Date: Aug-2015
MC-10113795-9999.pdf 288.079KB
NHTSA ID Number: 10142216
Manufacturer Communication Number: PI1317
Summary
This preliminary bulletin provides a procedure to repair the outside door handle and the liftgate release handle lock release cable to correct the customers concern of the rear liftgate wont open with the outside handle.
1 Associated Document
Manufacturer Communications
Bulletin No.: PI1317
Date: September, 2014
MC-10142216-9999.pdf 411.723KB
NHTSA ID Number: 10137795
Manufacturer Communication Number: PI1317
Summary
This preliminary bulletin provides a procedure to repair the outside door handle and the liftgate release handle lock release cable to correct the customers concern of the rear liftgate wont open with the outside handle.
1 Associated Document
Manufacturer Communications
Bulletin No.: PI1317
Date: September, 2014
MC-10137795-9999.pdf 411.723KB
NHTSA ID Number: 10072530
Manufacturer Communication Number: PI1317
Summary
SUMMARY TO BE PROVIDED ON A FUTURE DATE.
1 Associated Document
Service Bulletin Document
Bulletin No.: PI1317
Date: September, 2014
SB-10072530-0335.pdf 411.723KB
