Rear Spoiler Foam Tape Seal Loose, Visible to Customer – 2022-2023 Chevrolet Bolt EUV

SEOCONTENT-START

Copyright 2022 General Motors LLC. All Rights Reserved. Service Bulletin Bulletin No.: 22-NA-004 Date: September, 2022 TECHNICAL Subject: Rear Spoiler Foam Tape Seal Loose, Visible to Customer Brand: Model: Model Year: VIN: Engine: Transmission: from to from to Chevrolet Bolt EUV 2022 2023 — — All All Involved Region or Country North America, Middle East, GM Korea Company Condition 5950651 5950652 Page 2 September, 2022 Bulletin No.: 22-NA-004 5950653 Some customers may comment that the rear spoiler foam tape seal is visible and protruding from the roof line. Cause The cause of the condition may be that the foam tape seal on the rear spoiler is improperly installed and is detaching from the underside of the spoiler. Correction R & R the rear spoiler and replace the seal with a new service part, following the steps in the Service Procedure below. Service Procedure Important: Service agents must comply with all International, Federal, State, Provincial, and/or Local laws applicable to the activities it performs under this bulletin, including but not limited to handling, deploying, preparing, classifying, packaging, marking, labeling, and shipping dangerous goods. In the event of a conflict between the procedures set forth in this bulletin and the laws that apply to your dealership, you must follow those applicable laws. Bulletin No.: 22-NA-004 September, 2022 Page 3 5491612 1. Remove the rear spoiler (3) from the vehicle. Refer to Rear End Spoiler Replacement in SI. 2. Lay the spoiler on a protected work surface. 5950654 3. Remove the spoiler foam tape seal from the spoiler. Page 4 September, 2022 Bulletin No.: 22-NA-004 5950655 5950657 4. Using Kent Automotive Acrysol, or equivalent, remove any backing tape or residue from the spoiler. 5950662 Bulletin No.: 22-NA-004 September, 2022 Page 5 5. Final clean the surface with an alcohol wipe. 5950666 Note: Make sure the spoiler surface is clean and dry before attempting to install the new seal. 6. Inspect the surface to ensure all residual foam seal tape and adhesive has been removed. 5950668 7. Note the proper positioning of the foam tape seal. Approximately 3 mm (5/64”) from the curved contour (1), and approximately 5 mm (3/16”) from the end (2). 5950670 8. Partially peel the backing tape from the new foam tape seal and position the starting end, as shown in the graphic above. Page 6 September, 2022 Bulletin No.: 22-NA-004 5950674 Note: Be careful not to stretch the seal during installation. This could result in gaps or puckers and the seal not adhering tight to the spoiler in areas. 9. Slowly position and push down on the seal installing it to the flat, curved contour of the spoiler. 5950677 10. Verify the foam tape seal is completely adhered to the rear spoiler surface, paying special attention to the corners, ends, and areas where the contour changes. 5950680 11. The foam tape seal may require trimming at the finishing end. Bulletin No.: 22-NA-004 September, 2022 Page 7 5950681 12. The spoiler mounting surface on the liftgate may require cleaning before spoiler reinstall. Clean using GM P/N 19370290 glass cleaner, or equivalent. 5491612 13. Reinstall the rear spoiler (3). Refer to Rear End Spoiler Replacement in SI. Page 8 September, 2022 Bulletin No.: 22-NA-004 Parts Information Note: The reason the part numbers were added to the Bulletin was as Reference Only, to drive a link to the bulletin in the GM Electronic Parts Catalog (EPC). Causal Part Description RPO Model Part Number Qty X INSULATOR-R/ END SPLR — — 42797143 1 Reference Only (Do Not Order) N/A SPOILER-R/END (PAINT TO MATCH) &DRZ, &U2Q FR48 42788642 — N/A SPOILER-R/END (PAINT TO MATCH) &DRZ, &U2Q FF48, FL48, FP48 42788618 — N/A SPOILER-R/END (PAINT TO MATCH) &U2Q, -DRZ FP48 42788626 — N/A SPOILER-R/END (PAINT TO MATCH) &DRZ, -U2Q FG48, FL48, FR48 42788634 — Warranty Information For vehicles repaired under the Bumper-to-Bumper coverage (Canada Base Warranty coverage), use the following labor operation. Reference the Applicable Warranties section of Investigate Vehicle History (IVH) for coverage information. Labor Operation Description Labor Time 1086468* Rear End Spoiler Seal Replacement 0.6 hr *This is a unique Labor Operation for bulletin use only. Version 3 Modified Released January 19, 2022 Revised March 18, 2022 – Added a table that provides the applicable paint to match rear spoiler Part Numbers. Revised September 14, 2022 – Added the 2023 Model Year and an Important statement. GM bulletins are intended for use by professional technicians, NOT a “do-it-yourselfer”. They are written to inform these technicians of conditions that may occur on some vehicles, or to provide information that could assist in the proper service of a vehicle. Properly trained technicians have the equipment, tools, safety instructions, and know-how to do a job properly and safely. If a condition is described, DO NOT assume that the bulletin applies to your vehicle, or that your vehicle will have that condition. See your GM dealer for information on whether your vehicle may benefit from the information. WE SUPPORT VOLUNTARY TECHNICIAN CERTIFICATION

**************************************************************************************************************

**************************************************************************************************************
