NHTSA ID Number: 10219389
Manufacturer Communication Number: 21-NA-061
Summary
This service bulletin provides information for dealers on Using EL-52545 When Diagnosing PEPs Transmitter Key Fobs (North America ONLY).
The EL-52545 TPMS and RF Tool must be used to verify that the VIN learned to the transmitter key fob matches the VIN of the service vehicle as part of the diagnostic procedure.
This bulletin provides information on how to use this Special Tool to identify key fob information, including the last eight digits of the VIN associated with the fob.
The EL-52545 TPMS and RF Tool ‘Signal Detection Screen’ displays the VIN and other information imbedded in the key fob.
175 Affected Products
Vehicles
| MAKE | MODEL | YEAR |
BUICK | ENCLAVE | 2020-2023 |
| BUICK | ENCORE | 2020-2022 |
| BUICK | ENCORE GX | 2020-2022 |
| BUICK | ENVISION | 2020-2022 |
| BUICK | LACROSSE | 2020 |
| BUICK | REGAL | 2020 |
| CADILLAC | CT4 | 2020-2022 |
| CADILLAC | CT5 | 2020-2022 |
| CADILLAC | CT6 | 2020-2021 |
| CADILLAC | ESCALADE | 2020-2023 |
| CADILLAC | ESCALADE ESV | 2020-2022 |
| CADILLAC | LYRIQ | 2023 |
| CADILLAC | XT4 | 2020-2022 |
| CADILLAC | XT5 | 2020-2023 |
| CADILLAC | XT6 | 2020-2023 |
| CADILLAC | XTS | 2020 |
| CHEVROLET | 3500 | 2020-2022 |
| CHEVROLET | 4500 | 2020, 2022 |
| CHEVROLET | 4500HD | 2020-2022 |
| CHEVROLET | 4500XD | 2020-2022 |
| CHEVROLET | 5500HD | 2020-2022 |
| CHEVROLET | 5500XD | 2020-2022 |
| CHEVROLET | 6500HD | 2022 |
| CHEVROLET | BLAZER | 2020-2023 |
| CHEVROLET | BOLT EUV | 2022-2023 |
| CHEVROLET | BOLT EV | 2020-2023 |
| CHEVROLET | CAMARO | 2020-2023 |
| CHEVROLET | COLORADO | 2020-2022 |
| CHEVROLET | CORVETTE | 2020-2023 |
| CHEVROLET | EQUINOX | 2020-2022 |
| CHEVROLET | EXPRESS | 2020-2022 |
| CHEVROLET | IMPALA | 2020 |
| CHEVROLET | MALIBU | 2020-2022 |
| CHEVROLET | SILVERADO 1500 | 2020-2023 |
| CHEVROLET | SILVERADO 2500 | 2020-2023 |
| CHEVROLET | SILVERADO 3500 | 2020-2023 |
| CHEVROLET | SILVERADO 4500HD | 2020-2023 |
| CHEVROLET | SILVERADO 5500HD | 2020-2023 |
| CHEVROLET | SILVERADO 6500HD | 2020-2023 |
| CHEVROLET | SONIC | 2020 |
| CHEVROLET | SPARK | 2020-2022 |
| CHEVROLET | SUBURBAN | 2020-2023 |
| CHEVROLET | SUBURBAN 1500 | 2021-2022 |
| CHEVROLET | TAHOE | 2020-2023 |
| CHEVROLET | TRAILBLAZER | 2020-2022 |
| CHEVROLET | TRAVERSE | 2020-2023 |
| CHEVROLET | TRAX | 2020-2022 |
| GMC | ACADIA | 2020-2023 |
| GMC | CANYON | 2020-2022 |
| GMC | HUMMER EV | 2022-2023 |
| GMC | SAVANA | 2020-2022 |
| GMC | SIERRA 1500 | 2020-2023 |
| GMC | SIERRA 2500 | 2020-2023 |
| GMC | SIERRA 3500 | 2020-2023 |
| GMC | SIERRA DENALI | 2020 |
| GMC | TERRAIN | 2020-2022 |
| GMC | YUKON | 2020-2023 |
| GMC | YUKON XL | 2020-2022 |
1 Associated Document
Manufacturer Communications
Bulletin No.: 21-NA-061
Date: September, 2022
MC-10219389-0001.pdf 146.812KB
NHTSA ID Number: 10192031
Manufacturer Communication Number: 21NA061
Summary
This service bulletin provides information for dealers on Using EL-52545 When Diagnosing PEPs Transmitter Key Fobs (North America ONLY).
1 Associated Document
Manufacturer Communications
Bulletin No.: 21-NA-061
Date: March, 2021
