NHTSA ID Number: 10193459
Manufacturer Communication Number: PIP5803A
Summary
This Preliminary information communicates to technician’s if they remove the front timing cover when performing a repair, they should inspect the timing chain guide upper bolt for being loose. This document is an attempt to collect parts so engineering can investigate the concern.
62 Affected Products
Vehicles
| MAKE | MODEL | YEAR |
BUICK | ENVISION | 2016-2021 |
| BUICK | REGAL | 2016-2017 |
| CADILLAC | ATS | 2016-2018 |
| CADILLAC | CT6 | 2016-2018 |
| CADILLAC | CTS | 2016-2018 |
| CHEVROLET | BLAZER | 2019-2021 |
| CHEVROLET | CAMARO | 2016-2021 |
| CHEVROLET | COLORADO | 2016-2021 |
| CHEVROLET | EQUINOX | 2018-2021 |
| CHEVROLET | IMPALA | 2016-2018 |
| CHEVROLET | MALIBU | 2016-2021 |
| CHEVROLET | TRAVERSE | 2018-2019 |
| GMC | ACADIA | 2017-2021 |
| GMC | CANYON | 2016-2021 |
| GMC | TERRAIN | 2018-2021 |
Condition
If a technician is making a repair that requires the front timing cover to be removed and finds the timing chain guide upper bolt (circled) loose enough to turn by hand, replace the timing chain guide and bolts.
Cause
The cause of this loose bolt has not been determined yet and is being investigated by engineering.
Correction:
Replace the timing chain guide and bolts.
Parts Information
| Description | Part Number | Quantity |
| Guide, Timing Chain Assy | 12627111 | 1 |
