Accessory Off Road Lights Inoperative After Installation – 2016-2021 Chevrolet Colorado & GMC Canyon

“This site contains affiliate links for which OEMDTC may be compensated”

NHTSA ID Number: 10185723

Manufacturer Communication Number: PIT5516F



Summary

This Preliminary Information communicates the steps on diagnosing the concern of the accessory off road lamps are inoperative after installation.



12 Affected Products

Vehicles

MAKE MODEL YEAR
CHEVROLET COLORADO 2016-2021
GMC CANYON 2016-2021







NHTSA ID Number: 10083364

Manufacturer Communication Number: PIT5516



Summary

THIS PRELIMINARY INFORMATION COMMUNICATION PROVIDES INFORMATION TO THE TECHNICIAN ABOUT VEHICLES THAT HAVE ACCESSORY OFF ROAD LIGHTS INSTALLED FROM THE DEALER. NOW AFTER THE INSTALLATION THE LIGHTS ARE INOPERATIVE. TECHNICIAN WILL NEED TO VERIFY THE ENGINE IS RUNNING AND THE HEADLIGHTS ARE ON AND THE DAY TIME RUNNING LIGHTS AND THE SWITCH HAS BEEN PRESSED FOR 3 SECONDS. ALSO INSURE THE COVERS ARE NOT INSTALLED ON THE OFF ROAD LIGHTS. TECHNICIAN WILL NEED TO VERIFY THE BODY CONTROL MODULE PROGRAMMING. VEHICLES WITH REGULAR PRODUCTION OPTION CODE S3X THE BODY CONTROL MODULE IS PROGRAMMED FOR THE LIGHTS. FOR VEHICLES THAT DO NOT HAVE REGULAR PRODUCTION OPTION CODE S3X TECHNICIAN TILL NEED TO CALL TECHLINE CUSTOMER SUPPORT CENTER FOR PROGRAMMING ASSISTANCE. TECHNICIAN SHOULD TEST THE HEADLIGHT SWITCH TERMINAL 6 FOR SYSTEM VOLTAGE. IF NO VOLTAGE PRESENT O TERMINAL 6 CHECK THE BODY CONTROL MODULE X1 TERMINAL 12 FOR THE PROPER INSTALLATION. REPAIR AND TERMINAL DAMAGED OR NOT INSTALLED CORRECTLY. THEN REMOVE BODY CONTROL MODULE CONNECTOR X5 AND APPLY VOLTAGE TO TERMINAL 5, IF THE LIGHTS NOW ILLUMINATE IT IS LIKELY THE INCORRECT TERMINAL HAS BEEN USED IN THIS POSITION, REFER TO SERVICE INFORMATION FOR THE APPROPRIATE TEST TOOL AND TERMINAL.



1 Associated Document

Service Bulletin Document

Bulletin No.: PIT5516
Date: Aug-2016

https://www.nhtsa.gov/recalls?nhtsaId=10083364

SB-10083364-5448.pdf 77.664KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [75.84 KB]




Manufacturer Communication Number: PIT5516A



Summary

This Preliminary Information communicates the steps on diagnosing the concern of the accessory off road lamps are inoperative after installation.



1 Associated Document

Manufacturer Communications

Bulletin No.: PIT5516A
Published date: 10/16/2017

https://www.nhtsa.gov/recalls?nhtsaId=10123260

MC-10123260-9999.pdf 67.919KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [66.33 KB]




1 Associated Document

Manufacturer Communications

Bulletin No.: PIT5516F
Published date: 12/10/2020

https://www.nhtsa.gov/recalls?nhtsaId=10185723

MC-10185723-9999.pdf 72.804KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [71.10 KB]
