NHTSA ID Number: 10139281
Manufacturer Communication Number: 140879001C
Summary
This informational bulletin provides a list of parts/replacement parts for the tonneau covers.
13 Affected Products
Vehicles
MAKE | MODEL | YEAR |
CHEVROLET | SILVERADO | 2017 |
CHEVROLET | SILVERADO 1500 | 2014 |
CHEVROLET | SILVERADO 2500 | 2015-2016, 2018 |
GMC | SIERRA | 2017 |
GMC | SIERRA 1500 | 2014 |
GMC | SIERRA 2500 | 2015-2016, 2018 |
GMC | SIERRA DENALI | 2015-2016, 2018 |
Parts
Accessory Tonneau Cover / Soft Rollups.
22772361, 22772362, 22772363, 22772364, 22772365, 22772366, 22998717, 22998718 | 23128997 | Rear Latches (ALL) |
22772363, 22772366, 22998717, 22998718 (All 8’) | 22878369 | 8’ Side Rail (RH) |
22772363, 22772366, 22998717, 22998718 (All 8’) | 22878366 | 8’ Side Rail (LH) |
22772362, 22772365 (All 6’6”) | 22878368 | 6’6” Side Rail (RH) |
22772362, 22772365 (All 6’6”) | 22878365 | 6’6” Side Rail (LH) |
22772361, 22772364 (All 5’8”) | 22878367 | 5’8” Side Rail (RH) |
22772361, 22772364 (All 5’8”) | 22878749 | 5’8” Side Rail (LH) |
22772361, 22772362, 22772363, 22772364, 22772365, 22772366, 22998717, 22998718 | 19165160 | Retention Strap (ALL) |
22772361, 22772362, 22772363, 22772364, 22772365, 22772366, 22998717, 22998718 | 19202599 | Side Rail End Cap (ALL) |
22772361 | 22878336 | 5’8” Chevy Cover Kit (Vinyl) |
22772364 | 22878337 | 5’8” GMC Cover Kit (Vinyl) |
22772362 | 22878338 | 6’6” Chevy Cover Kit (Vinyl) |
22772365 | 22878339 | 6’6” GMC Cover Kit (Vinyl) |
22772363 | 22878340 | 8’ Chevy Cover Kit (Vinyl) |
22772366 | 22878341 | 8’ GMC Cover Kit (Vinyl) |
22772361, 22772362, 22772364, 22772365 | 22878359 | Cross Bow #1 (All 5’8” & 6’6”) |
22772361, 22772362, 22772364, 22772365 | 22878360 | Cross Bow #2 (All 5’8” & 6’6”) |
22772361, 22772362, 22772364, 22772365 | 22878361 | Cross Bow #3 (All 5’8” & 6’6”) |
22772363, 22772366, 22998717, 22998718 | 22878362 | Cross Bow #1 (All 8’) |
22772363, 22772366, 22998717, 22998718 | 22878363 | Cross Bow #2 (All 8’) |
22772363, 22772366, 22998717, 22998718 | 22878364 | Cross Bow #3 (All 8’) |
22772363, 22772366, 22998717, 22998718 | 22878748 | Cross Bow #4 (All 8’) |
22772361, 22772362, 22772363, 22772364, 22772365, 22772366 | 22878355 | Clamp #1 (All except Dually) |
22772361, 22772362, 22772363, 22772364, 22772365, 22772366 | 22878356 | Clamp #2 (All except Dually) |
22772361, 22772362, 22772363, 22772364, 22772365, 22772366 | 22878357 | Clamp #3 (All except Dually) |
22998717, 22998718 | 23112503 | Clamp #3 (Dually Only) |
22998717, 22998718 | 23112504 | Clamp #2 (Dually Only) |
22998717, 22998718 | 23112505 | Clamp #1 (Dually Only) |
Accessory Tonneau Cover / Soft & Hard Tri-Fold.
22895471, 22895472, 22895473, 23139840, 23139841, 23139842, 22834742, 22834743, 22834744, 23139843, 23139844, 23139845 | 22840915 | Rear Clamp Kit (ALL) |
22895471, 22895472, 22895473, 23139840, 23139841, 23139842, 22834742, 22834743, 22834744, 23139843, 23139844, 23139845 | 22900402 | Perimeter Seal 6’ Roll (ALL) |
22895471, 22895472, 22895473, 23139840, 23139841, 23139842, 22834742, 22834743, 22834744, 23139843, 23139844, 23139845 | 22817308 | Buckle Kit (ALL) |
22895471, 22895472, 22895473, 23139840, 23139841, 23139842, 22834742, 22834743, 22834744, 23139843, 23139844, 23139845 | 19169957 | Beauty Cover 3’ Strip (ALL) |
22895471, 22895472, 22895473, 23139840, 23139841, 23139842, 22834742, 22834743, 22834744, 23139843, 23139844, 23139845 | 23106155 | Striker Assembly (ALL) |
22895471, 22895472, 22895473, 23139840, 23139841, 23139842, 22834742, 22834743, 22834744, 23139843, 23139844, 23139845 | 22900409 | Corner Pad (ALL) |
SEOCONTENT-START
#14-08-79-001C: Accessory Tonneau Cover Service Parts – (Jan 19, 2018)
Subject: | Accessory Tonneau Cover Service Parts |
Models: | 2014 Chevrolet Silverado 1500 |
2015-2018 Chevrolet Silverado | |
2014 GMC Sierra 1500 | |
2015-2018 GMC Sierra | |
Equipped with Accessory Tonneau Cover (RPOs 5JY, VPB, VQT) | |
Attention: | This Bulletin also applies to any of the above models that may be Export vehicles. |
This Bulletin has been revised to add the 2017 and 2018 Model Years. Please discard Corporate Bulletin Number 14-08-79-001B.
The purpose of this bulletin is to advise dealership personnel that when replacement parts are needed for the tonneau cover, DO NOT order the entire tonneau cover as the replacement parts are now serviced individually.
Parts Information
Reference the table below for a list of service components for the Accessory Tonneau Cover / Soft Rollups.
Component of Package | Service Part Number | Service Part Description |
22772361, 22772362, 22772363, 22772364, 22772365, 22772366, 22998717, 22998718 | 23128997 | Rear Latches (ALL) |
22772363, 22772366, 22998717, 22998718 (All 8’) | 22878369 | 8’ Side Rail (RH) |
22772363, 22772366, 22998717, 22998718 (All 8’) | 22878366 | 8’ Side Rail (LH) |
22772362, 22772365 (All 6’6”) | 22878368 | 6’6” Side Rail (RH) |
22772362, 22772365 (All 6’6”) | 22878365 | 6’6” Side Rail (LH) |
22772361, 22772364 (All 5’8”) | 22878367 | 5’8” Side Rail (RH) |
22772361, 22772364 (All 5’8”) | 22878749 | 5’8” Side Rail (LH) |
22772361, 22772362, 22772363, 22772364, 22772365, 22772366, 22998717, 22998718 | 19165160 | Retention Strap (ALL) |
22772361, 22772362, 22772363, 22772364, 22772365, 22772366, 22998717, 22998718 | 19202599 | Side Rail End Cap (ALL) |
22772361 | 22878336 | 5’8” Chevy Cover Kit (Vinyl) |
22772364 | 22878337 | 5’8” GMC Cover Kit (Vinyl) |
22772362 | 22878338 | 6’6” Chevy Cover Kit (Vinyl) |
22772365 | 22878339 | 6’6” GMC Cover Kit (Vinyl) |
22772363 | 22878340 | 8’ Chevy Cover Kit (Vinyl) |
22772366 | 22878341 | 8’ GMC Cover Kit (Vinyl) |
22772361, 22772362, 22772364, 22772365 | 22878359 | Cross Bow #1 (All 5’8” & 6’6”) |
22772361, 22772362, 22772364, 22772365 | 22878360 | Cross Bow #2 (All 5’8” & 6’6”) |
22772361, 22772362, 22772364, 22772365 | 22878361 | Cross Bow #3 (All 5’8” & 6’6”) |
22772363, 22772366, 22998717, 22998718 | 22878362 | Cross Bow #1 (All 8’) |
22772363, 22772366, 22998717, 22998718 | 22878363 | Cross Bow #2 (All 8’) |
22772363, 22772366, 22998717, 22998718 | 22878364 | Cross Bow #3 (All 8’) |
22772363, 22772366, 22998717, 22998718 | 22878748 | Cross Bow #4 (All 8’) |
22772361, 22772362, 22772363, 22772364, 22772365, 22772366 | 22878355 | Clamp #1 (All except Dually) |
22772361, 22772362, 22772363, 22772364, 22772365, 22772366 | 22878356 | Clamp #2 (All except Dually) |
22772361, 22772362, 22772363, 22772364, 22772365, 22772366 | 22878357 | Clamp #3 (All except Dually) |
22998717, 22998718 | 23112503 | Clamp #3 (Dually Only) |
22998717, 22998718 | 23112504 | Clamp #2 (Dually Only) |
22998717, 22998718 | 23112505 | Clamp #1 (Dually Only) |
Reference the table below for a list of Service Components for the Accessory Tonneau Cover / Soft & Hard Tri-Fold.
Component of Package | Service Part Number | Service Part Description |
22895471, 22895472, 22895473, 23139840, 23139841, 23139842, 22834742, 22834743, 22834744, 23139843, 23139844, 23139845 | 22840915 | Rear Clamp Kit (ALL) |
22895471, 22895472, 22895473, 23139840, 23139841, 23139842, 22834742, 22834743, 22834744, 23139843, 23139844, 23139845 | 22900402 | Perimeter Seal 6’ Roll (ALL) |
22895471, 22895472, 22895473, 23139840, 23139841, 23139842, 22834742, 22834743, 22834744, 23139843, 23139844, 23139845 | 22817308 | Buckle Kit (ALL) |
22895471, 22895472, 22895473, 23139840, 23139841, 23139842, 22834742, 22834743, 22834744, 23139843, 23139844, 23139845 | 19169957 | Beauty Cover 3’ Strip (ALL) |
22895471, 22895472, 22895473, 23139840, 23139841, 23139842, 22834742, 22834743, 22834744, 23139843, 23139844, 23139845 | 23106155 | Striker Assembly (ALL) |
22895471, 22895472, 22895473, 23139840, 23139841, 23139842, 22834742, 22834743, 22834744, 23139843, 23139844, 23139845 | 22900409 | Corner Pad (ALL) |
SEOCONTENT-END
Bulletin No.: 14-08-79-001C
Date: January, 2018
https://www.nhtsa.gov/recalls?nhtsaId=10139281
https://static.nhtsa.gov/odi/tsbs/2018/MC-10139281-9999.pdf
To View or Download this Document Click Here
Bulletin No.: 14-08-79-001B
Date: April, 2016
https://www.nhtsa.gov/recalls?nhtsaId=10078473
https://static.nhtsa.gov/odi/tsbs/2016/MC-10078473-7690.pdf
To View or Download this Document Click Here
Bulletin No.: 14-08-79-001A
Date: October, 2014
https://www.nhtsa.gov/recalls?nhtsaId=10114285
https://static.nhtsa.gov/odi/tsbs/2014/MC-10114285-9999.pdf
To View or Download this Document Click Here
