NHTSA ID Number: 10079305
Manufacturer Communication Number: G-208267
Summary
14300A – SERVICE UPDATE (REVISED PART, SERVICE, AND WARRANTY INFORMATION). ON VEHICLES EQUIPPED WITH A POWER LIFTGATE (TB5/TC2), THE POWER LIFTGATE MAY HAVE BEEN BUILT WITH LIFTGATE STRUTS THAT CAN LOCK UP AND CEASE TO MOVE. IF THE LIFTGATE STRUT LOCKS UP, THE CUSTOMER MAY NOT BE ABLE TO OPEN OR CLOSE THE LIFTGATE EITHER ELECTRONICALLY OR MANUALLY. DEALERS ARE TO REPLACE THE LIFTGATE ACTUATOR ASSEMBLY.
This bulletin provides a service procedure to replace the liftgate actuator assembly on certain 2015 model year Cadillac Escalade and Escalade ESV, Chevrolet Suburban and Tahoe, and GMC Yukon and Yukon XL vehicles equipped with a power liftgate (TB5/TC2). The power liftgate on these vehicles may have been built with liftgate struts that can lock up and cease to move. If the liftgate strut locks up, the customer may not be able to open or close the liftgate either electronically or manually.
This service procedure should be completed as soon as possible on involved vehicles currently in dealer inventory and customer vehicles that return to the dealer for any type of service during the New Vehicle Limited Warranty coverage period.
Parts
Description | Quantity/Vehicle | Part Number |
ACTUATOR ASM-L/GATE PWR ASST (LH) | 1 | 23226162 |
#8 Self-tapping Screw (1-1/2 “ Long) | 1 | Obtain Locally |
6 Affected Products
Vehicles
MAKE | MODEL | YEAR |
CADILLAC | ESCALADE | 2015 |
CADILLAC | ESCALADE ESV | 2015 |
CHEVROLET | SUBURBAN | 2015 |
CHEVROLET | TAHOE | 2015 |
GMC | YUKON | 2015 |
GMC | YUKON XL | 2015 |
1 Associated Document
Service Bulletin Document
GM Bulletin No.: 14300A
Date: January 2015
https://www.nhtsa.gov/recalls?nhtsaId=10079305
SB-10079305-0335.pdf 534.363KB
NHTSA ID Number: 10081072
Manufacturer Communication Number: G-204813
Summary
14300 – SERVICE UPDATE. THIS BULLETIN PROVIDES A SERVICE PROCEDURE TO REPLACE THE LIFTGATE ACTUATOR ASSEMBLY ON CERTAIN VEHICLES EQUIPPED WITH A POWER LIFTGATE (TB5/TC2). THE POWER LIFTGATE ON THESE VEHICLES MAY HAVE BEEN BUILT WITH LIFTGATE STRUTS THAT CAN LOCK UP AND CEASE TO MOVE. IF THE LIFTGATE STRUT LOCKS UP, THE CUSTOMER MAY NOT BE ABLE TO OPEN OR CLOSE THE LIFTGATE EITHER ELECTRONICALLY OR MANUALLY.
1 Associated Document
Service Bulletin Document
GM Bulletin No.: 14300
Date: December 2014
https://www.nhtsa.gov/recalls?nhtsaId=10081072
NHTSA ID Number: 10067349
Manufacturer Communication Number: 14300
Summary
SUMMARY TO BE PROVIDED ON A FUTURE DATE.
1 Associated Document
Service Bulletin Document
GM Bulletin No.: 14300
Date: December 2014
https://www.nhtsa.gov/recalls?nhtsaId=10067349
SB-10067349-9133.pdf 350.187KB
NHTSA ID Number: 10090072
Manufacturer Communication Number: 14300 CANCEL SUS
Summary
14300 – SERVICE UPDATE (RESUME REPAIRS MESSAGE ONLY). ON MARCH 5, 2015, DEALERS WERE SENT A MESSAGE INFORMING THEM TO SUSPEND REPAIRS FOR SERVICE UPDATE 14300 DUE TO A POSSIBLE QUALITY ISSUE ON THE ACTUATOR ASSEMBLY USED TO PERFORM THE REPAIR. OUR INVESTIGATION HAS COMPLETED AND NO QUALITY ISSUES WERE FOUND. EFFECTIVE IMMEDIATELY, REPAIRS CAN NOW BEGIN AGAIN ON INVOLVED VEHICLES.
1 Associated Document
Manufacturer Communications
GM CUSTOMER CARE AND AFTERSALES
DCS3608
March 31, 2015
NHTSA ID Number: 10090075
Manufacturer Communication Number: 14300
Summary
14300 – SERVICE UPDATE (SUSPEND REPAIRS MESSAGE ONLY). UNTIL FURTHER NOTICE, DEALERS ARE TO SUSPEND ALL REPAIRS FOR SERVICE UPDATE 14300.
1 Associated Document
Manufacturer Communications
GM CUSTOMER CARE AND AFTERSALES
DCS3574
March 5, 2015
