NHTSA ID Number: 10161005
Manufacturer Communication Number: PIT5412D
Summary
This Preliminary Information communication provides information to the technician about vehicles that have either the truck or the snowplow’s headlights are flickering or inoperative. There may be a diagnostic trouble code B2575 and or a B2699 set in the body control module. Technician will need to contact the snowplow manufacturer for additional information on their headlight changeover system. Technician is to refer to the latest version of the General Motors up-fitter integration bulletin 116 for additional information these circuits. Technician can find this information at https://www.gmupfitter.com/, under the “Technical Bulletin” Tab and then “Show all bulletins.”
14 Affected Products
Vehicles
MAKE | MODEL | YEAR |
CHEVROLET | SILVERADO | 2017 |
CHEVROLET | SILVERADO 1500 | 2014 |
CHEVROLET | SILVERADO 2500 | 2015-2016, 2018-2019 |
CHEVROLET | SILVERADO 4500HD | 2019 |
GMC | SIERRA | 2017 |
GMC | SIERRA 1500 | 2014-2016 |
GMC | SIERRA 2500 | 2019 |
GMC | SIERRA 3500 | 2018 |
GMC | SIERRA DENALI | 2019 |
SEOCONTENT-START
Bulletin No.: PIT5412D
Published date: 05/13/2019
Preliminary Information
PIT5412D Headlight Flicker or Inoperative When Switching
Between The Truck and Snow Plow Headlights
Models
Brand: Model: Model Years:
VIN:
Engine: Transmissions:
from to
Chevrolet Silverado 1500 2014 All All All All
Chevrolet Silverado 2015 – 2018 All All All All
Chevrolet Silverado LD 2019 All All All All
Chevrolet Silverado 2500/3500 2019 All All All All
GMC Sierra 1500 2014 All All All All
GMC Sierra 2015 – 2018 All All All All
GMC Sierra Limited 2019 All All All All
GMC Sierra 2500/3500 2019 All All All All
Supersession Statement
This PI was superseded to add the 2019 models. Please discard PIT5412C.
The following diagnosis might be helpful if the vehicle exhibits the symptom(s) described in this PI.
Condition / Concern
Some owners with snow plow equipment, may notice that either the truck or the snowplow’s
headlights are flickering or Inoperative. This may affect either the LH or the RH lamp
assembly. This may also occur when switching back and forth between the truck and the
snow plow headlights. When checking for DTC’s, the BCM may or may not set a B2575 and/or
B2699.
Some snow plow manufacturers offer a headlight changeover module for switching between
the truck’s headlights and the snowplow’s headlights. Depending on the type of headlights
the truck is equipped with and the way they are controlled the headlight changeover module
may not operate correctly with the truck’s headlight system. This can cause either or both
the truck or snow plow headlights to flicker during changeover.
Recommendations / Instructions
This is not an issue with the truck’s headlight system. Contact the snowplow
manufacturer/upfitter for additional information on their headlight changeover system.
Also, please reference the latest version of GM Upfitter Integration Bulletin 116 for
additional information on these circuits. It can be found at https://www.gmupfitter.com/,
under the “Technical Bulletin” Tab and then “Show all bulletins.”
Please follow this diagnostic or repair process thoroughly and complete each step. If the condition exhibited is
resolved without completing every step, the remaining steps do not need to be performed.
SEOCONTENT-END
Bulletin No.: PIT5412D
Published date: 05/13/2019
https://www.nhtsa.gov/recalls?nhtsaId=10161005
https://static.nhtsa.gov/odi/tsbs/2019/MC-10161005-9999.pdf
To View or Download this Document Click Here
Bulletin No.: PIT5412C
Published date: 01/19/2018
https://www.nhtsa.gov/recalls?nhtsaId=10129077
https://static.nhtsa.gov/odi/tsbs/2018/MC-10129077-9999.pdf
To View or Download this Document Click Here
Bulletin No.: PIT5412B
Date: Jan-2017
https://www.nhtsa.gov/recalls?nhtsaId=10113290
https://static.nhtsa.gov/odi/tsbs/2017/MC-10113290-9999.pdf
To View or Download this Document Click Here
Bulletin No.: PIT5412A
Date: Dec-2016
https://www.nhtsa.gov/recalls?nhtsaId=10111693
https://static.nhtsa.gov/odi/tsbs/2016/MC-10111693-9999.pdf
To View or Download this Document Click Here
Bulletin No.: PIT5412
Date: May, 2015
https://www.nhtsa.gov/recalls?nhtsaId=10059067
https://static.nhtsa.gov/odi/tsbs/2015/SB-10059067-8267.pdf
To View or Download this Document Click Here
GM UI Bulletin 116b
GM Upfitter Integration Bulletin 116
“This site contains affiliate links for which OEMDTC may be compensated” |
- Package Dimensions: 37.211 H x 21.59 L x 36.449 W (centimetres)
- Package Weight: 4.4 kilograms
- Fit type: Vehicle Specific
- Country of Origin : China
- Package Dimensions: 18.0 L x 21.0 H x 18.0 W (inches)
- Package Weight : 6.66 pounds
- Country of Origin : United States
- Part number: 64261-4
- FITMENT - New Universal Halogen Snow Plow Lights will fit but is not limited to the following manufactures: Blizzard, Meyer, Fisher, Boss, Western, Snow Way, Curtis, Snow Dog, Hinker and More! Replace for Part Number 1311100.
