NHTSA ID Number: 10017818
Manufacturer Communication Number: 050601026
Summary
INFORMATION ON USE OF BOLT EXTRACTOR TOOL KIT PART NUMBER EN-47702 FOR REMOVING BROKEN CYLINDER HEAD OR MAIN BEARING CAP BOLTS ON INLINE TRUCK ENGINES. *TT
25 Affected Products
Vehicles
| MAKE | MODEL | YEAR |
| BUICK | RAINIER | 2004-2006 |
| CHEVROLET | COLORADO | 2004-2006 |
| CHEVROLET | TRAILBLAZER | 2002-2006 |
| GMC | CANYON | 2004-2006 |
| GMC | ENVOY | 2002-2006 |
| HUMMER | H3 | 2006 |
| OLDSMOBILE | BRAVADA | 2002-2004 |
| SAAB | 9-7X | 2005-2006 |
A Torque To Yield (TTY) bolt, like a cylinder head bolt or main bearing cap bolt, may break during repair procedures.
Interaction between a TTY bolt and threads may cause the bolt to bind or break on removal.
Prior to removing the cylinder head or main cap bolts, perform the following procedure:
Using an appropriately sized punch and hammer, rap on the head of each bolt.
The vibration produced by this procedure will assist in successful removal.
If a head bolt or main bolt breaks during engine disassembly, a broken bolt extractor kit (EN-47702) has been released to assist in removal of the remaining bolt segment.
Many times the remaining bolt segment will back out easily with a pick tool or a reverse twist drill bit.
NHTSA ID Number: 10017818
Manufacturer Communication Number: 050601026
https://www.nhtsa.gov/recalls?nhtsaId=10017818
