NHTSA ID Number: 10220314
Manufacturer Communication Number: 22-NA-176
Summary
This technical bulletin provides information on a possible bolt and guide pin that may be missing from the control valve which will need to be installed to correct the repair.
Condition
Some technicians may comment on no movement after the valve body replacement.
Cause
This may be caused by a plug and retaining bolt missing on valve body.
Correction
Inspect for the plug (1) and retaining bolt (2) as noted in the graphic above.
If the plug and retaining bolt are missing, fill out the WPC part request form and send it to the WPC following the instructions below.
⇒ The plug and retaining bolt are packaged as a kit.
⇒ The kit part number is WPC 853 and can be obtained from the Warranty Parts Center (WPC) using the TSP Dealer Request Form This form is located on:
Global Connect<Service Department<Service Forms Application<General Information tab<TSP Dealer Request Form.
Instructions for submitting are on the form.
Request WPC###.
117 Affected Products
Vehicles
MAKE | MODEL | YEAR |
CADILLAC | ATS | 2016-2019 |
CADILLAC | ATS-V | 2016-2018 |
CADILLAC | CT4 | 2020-2022 |
CADILLAC | CT6 | 2016-2018 |
CADILLAC | CTS | 2016-2019 |
CADILLAC | CTS-V | 2016, 2018 |
CADILLAC | ESCALADE | 2016-2023 |
CADILLAC | ESCALADE ESV | 2016-2023 |
CHEVROLET | CAMARO | 2016-2022 |
CHEVROLET | CORVETTE | 2015-2019 |
CHEVROLET | EXPRESS | 2017-2022 |
CHEVROLET | SILVERADO 1500 | 2016-2022 |
CHEVROLET | TAHOE | 2015-2022 |
CHEVROLET | TAHOE POLICE PURSUIT | 2015-2016 |
GMC | SAVANA | 2016-2022 |
GMC | SAVANA 1500 | 2016-2017 |
GMC | SAVANA 2500 | 2016-2018 |
GMC | SAVANA 3500 | 2016-2018 |
GMC | SIERRA 1500 | 2016-2022 |
GMC | YUKON | 2015-2022 |
GMC | YUKON DENALI | 2015-2019 |
GMC | YUKON DENALI XL | 2015-2018 |
GMC | YUKON XL | 2015-2022 |
1 Associated Document
Manufacturer Communications
Bulletin No.: 22-NA-176
Date: September, 2022
https://www.nhtsa.gov/recalls?nhtsaId=10220314
MC-10220314-0001.pdf 100.949KB
