NHTSA ID Number: 10224291
Manufacturer Communication Number: PIP5810A
Summary
This Preliminary information communicates that the tool for the HD transfer cases to install the input seal during a repair is incorrect and a new tool is in development.
Condition
Transfer case input seal installation tool will not install seal to correct depth causing a leak.
Cause
New tool being developed.
16 Affected Products
Vehicles
| MAKE | MODEL | YEAR |
| CHEVROLET | SILVERADO 2500 | 2020-2023 |
| CHEVROLET | SILVERADO 3500 | 2020-2023 |
| GMC | SIERRA 2500 | 2020-2023 |
| GMC | SIERRA 3500 | 2020-2023 |
1 Associated Document
Manufacturer Communications
Bulletin No.: PIP5810A
Published date: 09/19/2022
https://www.nhtsa.gov/recalls?nhtsaId=10224291
MC-10224291-9999.pdf 1001.044KB
Loading...
Reload document
Open in new tab
NHTSA ID Number: 10201286
Manufacturer Communication Number: PIP5810
Summary
This Preliminary information communicates that the tool for the HD transfer cases to install the input seal during a repair is incorrect and a new tool is in development.
1 Associated Document
Manufacturer Communications
Bulletin No.: PIP5810
Published date: 06/16/2021
https://www.nhtsa.gov/recalls?nhtsaId=10201286
MC-10201286-9999.pdf 1004.226KB
Loading...
