NHTSA ID Number: 10199233
Manufacturer Communication Number: 18NA275
Summary
This service bulletin provides information on a small allowable amount of grease seepage from a brass or gold colored fitting located at the bottom of the strut assemblies, which is actually part of the natural operation of these struts.
6 Affected Products
Vehicle
| MAKE | MODEL | YEAR |
| CHEVROLET | CAMARO | 2014-2015, 2018-2021 |
Condition
Some customers and/or technicians may comment on a small amount of grease seepage from a brass or gold colored fitting located at the bottom of the strut assemblies. Note: At first glance, this may appear to be a fluid leak.
The 5th generation Camaro Z/28, as well as the 6th generation Camaro ZL1 1LE, employ a different type of strut than other traditional car and truck lines. These struts are specifically designed and tuned for the precise vehicle handling that these vehicles are capable of.
Cause
This condition may be caused by a vent allowing breathing within the damper body. There is no oil within this chamber but there is some grease on the inner walls of the housing that keeps the insert tubing lubricated against the component’s bushings. As air enters and exits this vent, it is normal to have small amounts of this grease exit the strut. This is actually part of the natural operation of these struts.
Correction
No strut replacement is required for this condition listed above.
SEOCONTENT-START
Service Bulletin Bulletin No.: 18-NA-275
Date: May, 2021
INFORMATION
Subject: Information on Grease Seepage from Strut Assemblies
Brand: Model:
Model Year: VIN:
Engine: Transmission:
from to from to
Chevrolet
Camaro Z28 2014 2015
— —
7.0L (LS7)
Camaro —
ZL1-1LE 2018 2021 6.2L (LT4)
Involved Region or Country North America, Brazil, Europe, Middle East, GM Korea Company, China, Japan
Additional Options (RPOs) Equipped with SUSPENSION SYSTEM-RIDE, HANDLING, PERFORMANCE, VAR 2
(RPO FEA)
Condition
5141833
Page 2 May, 2021 Bulletin No.: 18-NA-275
5141823
Some customers and/or technicians may comment on a small amount of grease seepage
from a brass or gold colored fitting located at the bottom of the strut assemblies.
Note: At first glance, this may appear to be a fluid leak.
The 5th generation Camaro Z/28, as well as the 6th generation Camaro ZL1 1LE, employ
a different type of strut than other traditional car and truck lines. These struts are
specifically designed and tuned for the precise vehicle handling that these vehicles are
capable of.
Cause
This condition may be caused by a vent allowing breathing within the damper body. There
is no oil within this chamber but there is some grease on the inner walls of the housing
that keeps the insert tubing lubricated against the component’s bushings. As air enters
and exits this vent, it is normal to have small amounts of this grease exit the strut. This is
actually part of the natural operation of these struts.
Correction No strut replacement is required for this condition listed above.
Version 2
Modified Released September 07, 2018
May 14, 2021 – Added the 2020–2021 Model Years and updated the Involved Region or
Country section.
SEOCONTENT-END
1 Associated Document
Manufacturer Communications
Bulletin No.: 18-NA-275
Date: May, 2021
MC-10199233-9999.pdf 185.973KB
