NHTSA ID Number: 10205562
Manufacturer Communication Number: 21NA233
Summary
This service bulletin advises the technician to order a winter grille cover if not found in vehicle or to install the cover one time.
4 Affected Products
Vehicle
MAKE | MODEL | YEAR |
CADILLAC | XT4 | 2019-2022 |
Information
The purpose of this bulletin is to:
- Verify that in extreme cold weather (-18°C or less / 0°F or less), a grille winter cover needs be added to avoid the customer returning with concerns related to charge air cooler icing.
- The customer must be educated by explaining the usage instructions from the instruction sheet and/or owner manual. Review the installation and removal procedure with the customer.
The winter grille cover should be included with the vehicle. If the winter grille cover is missing at PDI, order the winter grille cover using the unique labor code provided in the bulletin.
One time install of the winter grille cover is covered under warranty. This can be installed and charged to the unique Labor Operation code provided in the bulletin up to 12 months after delivery.
Important: The winter grille cover should be installed in the extreme cold weather and removed when the winter season changes.
Additional covers and repeat installation are customer pay.
Note: Clean the surface before installing the winter grille cover.
Parts Information
Causal Part | Description | Part Number | Qty |
N/A | COVER, FRT GRILLE | 85513002 | 1 |
SEOCONTENT-START
Service Bulletin Bulletin No.: 21-NA-233
Date: November, 2021
INFORMATION
Subject: Information on Charge Air Cooler Icing During Extreme Cold Weather Conditions
Brand: Model:
Model Year: VIN:
Engine: Transmission:
from to from to
Cadillac XT4 2019 2022 — —
2.0L
Turbo (LSY) —
Involved Region or Country United States, Canada
Additional Options (RPOs) HEATER ENG BLOCK, 110V (RPO K03)
Information
The purpose of this bulletin is to:
• Verify that in extreme cold weather (-18°C or less / 0°F or less), a grille winter cover
needs be added to avoid the customer returning with concerns related to charge air
cooler icing.
• The customer must be educated by explaining the usage instructions from the
instruction sheet and/or owner manual. Review the installation and removal procedure
with the customer.
The winter grille cover should be included with the vehicle. If the winter grille cover is
missing at PDI, order the winter grille cover using the unique labor code provided in the
bulletin.
One time install of the winter grille cover is covered under warranty. This can be installed
and charged to the unique Labor Operation code provided in the bulletin up to 12 months
after delivery.
Important: The winter grille cover should be installed in the extreme cold weather and
removed when the winter season changes.
Additional covers and repeat installation are customer pay.
Note: Clean the surface before installing the winter grille cover.
Parts Information
Causal
Part
Description Part
Number
Qty
N/A COVER, FRT
GRILLE
85513002 1
Page 2 November, 2021 Bulletin No.: 21-NA-233
Warranty Information
Note: If the vehicle came with the grille cover, use the
Labor Operation number below.
For vehicles repaired under the Bumper-to-Bumper
coverage (Canada Base Warranty coverage), use the
following labor operation. Reference the Applicable
Warranties section of Investigate Vehicle History (IVH)
for coverage information.
Labor
Operation
Description Labor Time
2086368* Install Grille Cover on XT4** 0.2 hr
*This is a unique Labor Operation for bulletin use only.
**Include PDI labor code with following restrictions; onetime
installation only, up to 12 months after sale, part
ceiling zero.
Warranty Information
Note: If the vehicle Did Not come with the grille cover,
use the Labor Operation number below.
For vehicles repaired under the Bumper-to-Bumper
coverage (Canada Base Warranty coverage), use the
following labor operation. Reference the Applicable
Warranties section of Investigate Vehicle History (IVH)
for coverage information.
Labor
Operation
Description Labor Time
4088228* Order Missing Grille Cover** 0.0 hr
*This is a unique Labor Operation for bulletin use only.
**Use REG labor code- Missing Cover at PDI only.
Version 1
Modified Released November 12, 2021
Additional SI Keywords: P0299, P0236, P2227, P00C7
SEOCONTENT-END
1 Associated Document
Manufacturer Communications
Bulletin No.: 21-NA-233
Date: November, 2021
https://www.nhtsa.gov/recalls?nhtsaId=10205562
MC-10205562-9999.pdf 504.468KB
