NHTSA ID Number: 10187739
Manufacturer Communication Number: PIE0603B
Summary
This engineering informational bulletin is requesting information from technicians to perform the check list provided and contact the engineer listed in regards to the rear sliding window leaking water.
2 Affected Products
Vehicles
MAKE | MODEL | YEAR |
CHEVROLET | SILVERADO 2500 | 2020 |
GMC | SIERRA 2500 | 2020 |
SEOCONTENT-START
Subject: Engineering Information – Sliding Rear Window Leaking Water
This PI has been revised to end the need for information from the field. Please discard PIE0603A.
Brand: Model: Model Year: Breakpoints: Engine: Transmission:
from to from to
Chevrolet Silverado 2500HD/3500HD 2020 2020 FLINT: VIN# LF262557 June
04, 2020
FORT WAYNE: VIN# LZ285396
June 05, 2020
SILAO: VIN# LG333724 June
05,2020 Applies to ONLY Crew
and Double Cab Models
All All
GMC Sierra 2500HD/3500HD
Version 3
Modified Released December 03, 2020
Revised December 07, 2020 – Revised to add Breakpoints.
December 15, 2020 – Ended the need for further information from the field.
1
***********************************************************************************************************
Subject: Engineering Information – Sliding Rear Window Leaking Water
Attention: Proceed with this EI ONLY if the customer has commented about this concern AND the PIE number is listed in the
Global Warranty Management / Investigate History link (GWM/IVH). If the customer has not commented about this
condition or the EI does not show in GWM/IVH, disregard the PIE and proceed with diagnostics found in published
service information. THIS IS NOT A RECALL — refer to Service Bulletin 04-00-89-053 for more details on the use of
Engineering Information bulletins.
This EI has been revised to add Breakpoints. Please discard PIE0603.
Brand: Model: Model Year: Breakpoints: Engine: Transmission:
from to from to
Chevrolet Silverado 2500HD/3500HD 2020 2020 FLINT: VIN# LF262557 June
04, 2020
FORT WAYNE: VIN# LZ285396
June 05, 2020
SILAO: VIN# LG333724 June
05,2020 Applies to ONLY Crew
and Double Cab Models
All All
GMC Sierra 2500HD/3500HD
Involved Region or Country North America
Additional Options (RPOs) Equipped with WINDOW RR-FULL WIDTH, SLIDING, POWER (Trucks with 4 doors only)
Condition Important: If the customer did not bring their vehicle in for this concern, DO NOT proceed with this EI.
Some customers may comment on the rear sliding window leaking water.
Cause GM Engineering is attempting to determine the root cause of the above condition. Engineering has a need to
gather information on vehicles PRIOR to repair that may exhibit this condition. As a result, this information will be
used to “root cause” the customer’s concern and develop/validate a field fix.
Correction
If you encounter a vehicle with the above concern, inspect for a water leak at the rear window and/or at the rear cab spoiler attachments and contact the engineers
listed below with your findings. Some leaks are being misdiagnosed and engineering is needing specific review of the spoiler and rear window. Refer to Rear Window
Replacement in SI.
Contact Information
Please include the following information if leaving a message:
– Technician name
– Dealer name and phone number
– Complete VIN and repair order (R.O) number
On the repair order, document the date and time the call was placed (even if the engineer was not reached).
If engineering is unable to return the call within one hour, proceed with diagnosis and repair based on information found in SI.
Warranty Information
1
The Contact Information has been redacted.
If engineer was contacted or required information was provided, use:
Labor Operation Description Labor Time
2086178* Engineering Information – Sliding Rear Window Leaking Water 0.8 hr
* This is a unique labor operation for bulletin use only.
Version 2
Modified Released December 03, 2020
Revised December 07, 2020 – Revised to add Breakpoints.
2
SEOCONTENT-END
