Safety Recall N202303150 Chassis Wiring Harness May Contact Leaf Spring Bracket – 2018-2020 Chevrolet 6500XD

“This site contains affiliate links for which OEMDTC may be compensated”

April 3, 2020 NHTSA CAMPAIGN NUMBER: 20V195000

Improperly Routed Chassis Wire Harness

Depending on which wires get damaged, the vehicle can experience stalling and/or reduced functionality of the ABS, increasing the risk of a crash.



NHTSA Campaign Number: 20V195

Manufacturer Isuzu Technical Center of America, Inc.

Components ELECTRICAL SYSTEM

Potential Number of Units Affected 2,399



Summary

Isuzu Technical Center of America, Inc. (Isuzu) is recalling certain 2018-2020 FTR and Chevrolet 6500XD vehicles. The chassis wire harness outside the relay box may have been improperly routed, potentially allowing the harness to contact the suspension’s leaf spring hanger bracket, allowing the harness to get chafed.



Remedy

Isuzu will notify owners, and dealers will repair or replace the existing wire harness, as necessary, and install additional clamps to ensure the wire harness is secured away from the hanger bracket, free of charge. The recall began May 15, 2020. Owners may contact Isuzu customer service at 1-866-441-9638. Isuzu’s number for this recall is V2003.



Notes

Owners may also contact the National Highway Traffic Safety Administration Vehicle Safety Hotline at 1-888-327-4236 (TTY 1-800-424-9153), or go to www.safercar.gov.



Check if your Vehicle has a Recall




Frequently Asked Questions (FAQs) for Safety Recall N202303150 Chassis Wiring Harness May Contact Leaf Spring Bracket



These questions and answers are being provided to help GM dealers respond to inquiries from involved vehicle owners about the Safety recall identified above.

Q1) Which vehicles are involved?
A1) 2018-2020 Chevrolet 6500XD Low Cab Forward Medium Duty Trucks.



Q2) What is the issue or condition?
A2) The chassis wire harness outside the relay box was improperly routed. As routed, it can contact the suspension’s leaf spring hanger bracket, causing the harness to chafe and the wires to be damaged.



Q3) What symptoms may be experienced?  What warning signs may be associated with the issue or condition described?
A3) There are numerous wires within the harness and circuits affected.  Depending on the circuit impacted, the driver may receive a warning and/or a warning light informing the driver that an underlying system has been affected.



Q4) What is the remedy/repair?
A4) The remedy will install two new clamps to ensure the harness does not contact the bracket.



Q5) What is the safety risk?  Is the vehicle safe to drive?
A5) Depending on which of the wires within the harness is affected, different systems could be impacted, yielding varying possible results including the possibility of a vehicle stall and/or reduced functionality of the ABS brake system. These results could increase the risk of a crash.



Q6) Does the customer have to pay for this remedy/repair?
A6) No, this inspection/repair will be done at no cost to the customer.



Q7) Is the remedy/repair available now?
A7) Yes.



Q8) What should customers do until recall repairs can be completed?  Are there any special instructions?
A8) If special instructions are provided, they will be included in the notification letters to customers.



Q9) How can customers check to see if their vehicle is involved in this field action?
A9) Customers who own a vehicle involved in the field action will be notified by mail by General Motors, but they may also check their Vehicle Identification Number (VIN) for field actions in GM Owner Center at https://my.gm.com/recalls or via NHTSA’s website at https://vinrcl.safercar.gov/vin/.



Q10) If customers are concerned, can they get a rental car or courtesy transportation?
A10) Courtesy transportation is not available for Medium Duty customers.






Representative Letter – Customer letters are brand, model and model year specific; listing the 17-digit VIN and are personalized.



IMPORTANT SAFETY RECALL



May 2020



This notice applies to your vehicle, VIN: __________________________________



Dear General Motors Customer:



This notice is sent to you in accordance with the National Traffic and Motor Vehicle Safety Act.



Isuzu Motors Limited has decided that a defect which relates to motor vehicle safety exists in certain 2018-2020 model year 6500XD Low Cab Forward vehicles.  As a result, GM is conducting a safety recall.  We apologize for this inconvenience.  However, we are concerned about your safety and continued satisfaction with our products.



I M P O R T A N T

  • Your vehicle is involved in GM recall N202303150.
  • Schedule an appointment with your GM dealer.
  • This service will be performed for you at no charge.



Why is your vehicle being recalled? The chassis wire harness outside the relay box was improperly routed. As routed, it can contact the suspension’s leaf spring hanger bracket, causing the harness to chafe and the wires to be damaged.  Depending on which of the wires within the harness are affected, different systems could be impacted, yielding varying possible results including the possibility of a vehicle stall and/or reduced functionality of the ABS brake system. These results could increase the risk of a crash.
What will we do? Your GM dealer will repair or replace the existing wire harness, as necessary, if it is damaged, and install additional clamps to ensure the undamaged or repaired/replacement wire harness is secured away from the hanger bracket.  This service will be performed for you at no charge.  Because of service scheduling requirements, it is likely that your dealer will need your vehicle longer than the actual time of approximately 1 hour and 35 minutes.
Did you already pay for this repair? Even though you may have previously had repairs for this condition, you will still need to take your vehicle to your dealer for additional repairs.  If you have already paid for repairs for the recall condition, please complete the enclosed reimbursement form and present it to your dealer with all required documents.  Working with your dealer will expedite your request, however, if this is not convenient, you may mail the completed reimbursement form and all required documents to Reimbursement Department, PO Box 33170, Detroit, MI 48232-5170.  The completed form and required documents must be presented to your dealer or received by the Reimbursement Department by May 31, 2021, unless state law specifies a longer reimbursement period.
What should you do? You should contact your GM dealer to arrange a service appointment as soon as possible.
Do you have questions? If you have questions or concerns that your dealer is unable to resolve, please contact the appropriate Customer Assistance Center at the number listed below.



Division Number Text Telephones (TTY)
Chevrolet 1-800-630-2438 1-800-833-2438
Puerto Rico – English 1-800-496-9992
Puerto Rico – Español 1-800-496-9993
Virgin Islands 1-800-496-9994



If after contacting your dealer and the Customer Assistance Center, you are still not satisfied we have done our best to remedy this condition without charge and within a reasonable time, you may wish to write the Administrator, National Highway Traffic Safety Administration, 1200 New Jersey Avenue, SE., Washington, DC 20590, or call the toll-free Vehicle Safety Hotline at 1.888.327.4236 (TTY 1.800.424.9153), or go to https://www.safercar.gov.  The National Highway Traffic Safety Administration Campaign ID Number for this recall is 20V195.



Federal regulation requires that any vehicle lessor receiving this recall notice must forward a copy of this notice to the lessee within ten days.



Maryann Combs
Vice President
Global Vehicle Safety



GM Recall N202303150
