NHTSA ID Number: 10163243
Manufacturer Communication Number: 19NA123
Summary
This technical bulletin provides repair information to correct a customer concern of the rear closure hands free lamp logo projection distorted.
1 Affected Product
Vehicle
| CHEVROLET | BLAZER | 2019 |
Parts
| SEAL-RR CLSR HANDS FREE LP | 84713687 | 1 |
SEOCONTENT-START
Service Bulletin Bulletin No.: 19-NA-123
Date: June, 2019
TECHNICAL
Subject: Rear Closure Hands Free Lamp Logo Projection Distorted
Brand: Model:
Model Year: VIN: Engine: Transmission:
from to from to
Chevrolet Blazer 2019 2019 All All
Involved Region or Country North America, N.A. Export Regions
Additional Options (RPOs) Equipped with BODY EQUIPMENT-LIFT GATE, POWER, HANDS FREE (TC2)
Page 2 June, 2019 Bulletin No.: 19-NA-123
Condition
5343103
Note: The projected logo shows where the hands free kicking motion is to take place. An
example is shown above.
5343106
Some customers may comment that the on-ground image of the rear closure hands free
lamp logo projection is distorted, and does not resemble the Chevrolet Bow Tie. Some
further comment that the logo lamp resembles a ‘C’ or a circle.
Cause The cause of the condition may be water entering between the rear closure hands free
lamp and lamp bracket, and gathering onto the lens of the lamp.
Bulletin No.: 19-NA-123 June, 2019 Page 3
Correction
5343112
Note: The illustration above shows a cross-section of the seal installed (1), which results
in blocking the main water path.
Following the steps in the Service Procedure below, add the service part foam seal
referenced in the Part Table.
Service Procedure
1. Raise and support the vehicle. Refer to Lifting and
Jacking the Vehicle, in SI.
5343109
Note: It is NOT necessary to remove the rear fascia or
disconnect the electrical connector.
2. Remove the 2 retaining screws (1), and reposition
the rear closure hands free lamp (2) away from the
lamp bracket.
5343118
Important: The adhesive side of the seal should be
placed on the lamp bracket.
Page 4 June, 2019 Bulletin No.: 19-NA-123
5343120
3. Install the new lamp seal (2) onto the lamp bracket,
at the interface between the lamp and bracket.
4. Reposition the rear closure hands free lamp (1) to
the seal and bracket, then reinstall the fasteners.
Tighten
Tighten the screws to 1.5Y(13 lb in).
5. Remove the support and lower the vehicle.
Parts Information
Causal
Part
Description Part
Number
Qty
N/A SEAL-RR CLSR
HANDS FREE LP
84713687 1
Warranty Information
For vehicles repaired under the Bumper-to-Bumper
coverage (Canada Base Warranty coverage), use the
following labor operation. Reference the Applicable
Warranties section of Investigate Vehicle History (IVH)
for coverage information.
Labor Operation Description Labor Time
2081968* Remove and Reinstall Rear Closure Hands Free Lamp,
Install Seal
0.4 hr
*This is a unique Labor Operation for Bulletin use only.
Version 1
Modified Released June 03, 2019
