NHTSA ID Number: 10163230
Manufacturer Communication Number: 18NA343
Summary
This technical bulletin provides a procedure to remove grease and install BRS tape to the spacers for the seat frame to eliminate a squeak type noise.
2 Affected Products
Vehicle
MAKE | MODEL | YEAR |
CADILLAC | CT6 | 2018-2019 |
Parts
BRS Tape | KT13487 | 1 |
SEOCONTENT-START
Service Bulletin Bulletin No.: 18-NA-343
Date: June, 2019
TECHNICAL
Subject: Lateral Seat Movement and/or Squeak Type Noise Heard in Driver Seat Cushion Area
Brand: Model:
Model Year: Breakpoint:
Engine: Transmission:
from to from to
Cadillac CT6 2018 2019
Involved Region or Country North America, Europe, Russia, Middle East, Israel, Japan, South Korea
Condition Some customers may comment on lateral seat movement and/or squeak type noise
heard in the driver seat cushion area.
Cause This condition may be caused by grease incorrectly applied in the seat frame area.
Correction Remove the grease and clean the area indicated following the Service Procedure below.
Service Procedure
1. Remove the driver seat and tilt back to see the
bottom of the seat. Refer to Driver or Passenger
Seat Removal and Installation in SI.
5154421
2. Remove the screws from the front handcuff
brackets (1) and the rear handcuff brackets (2).
Page 2 June, 2019 Bulletin No.: 18-NA-343
5154467
3. Remove the applicable wire harness, which allows
to fully remove the seats front two handcuff
brackets.
5154626
4. Remove the front seat handcuff brackets (1) and
the front spacers from the cross-bar (2).
5156068
Bulletin No.: 18-NA-343 June, 2019 Page 3
5156030
5. Using Kent Acrysol P20005 or equivalent, clean
the inside of the spacer and handcuff bracket.
Important: Make sure the cleaner does NOTerode the
plastic.
5356039
6. Using KENT KT13487 or equivalent, cut 4 pieces
(25 mm x 15 mm (1 in x 0.60 in) and apply it to the
center on both sides of each spacer, as shown in
the graphic above.
5156245
7. Using Kent Acrysol P20005 or equivalent, clean
the cross-bar.
Page 4 June, 2019 Bulletin No.: 18-NA-343
5156268
8. Remove old polyester felt from the support
stand-off.
9. Using KENT KT13486 or equivalent, cut 1 piece
(25 mm x 50 mm (1 in x 2 in) and apply it on the
support stand-off, as shown in the graphic above.
Parts Information
Contact Kent Automotive at 1-888-YES-KENTor online
at www.kent-automotive.com.
Causal
Part
Description Part
Number
Qty Material
Allowance
N/A* BRS Tape KT13487** 1
$0.35 USD
(per
vehicle)
$0.46 in
Canada
(per
vehicle)
*For warranty transactions, DO NOT mark this/these parts
as the Causal Part. Enter the word “Bulletin” in the Causal
Part Description free-flow text field.
**There is enough material to do approximately 56 vehicles.
Store the remaining material for further use.
Warranty Information
For vehicles repaired under the Bumper-to-Bumper
coverage (Canada Base Warranty coverage), use the
following labor operation. Reference the Applicable
Warranties section of Investigate Vehicle History (IVH)
for coverage information.
Labor
Operation
Description Labor Time
7086298* Removing Grease Off of
Seat Frame and Installing
BSR Tape to the Spacers
0.8 hr
*This is a unique Labor Operation for Bulletin use only.
Version 2
Modified Released November 14, 2018
June 12, 2019 – Added the 2019 Model Year, updated the Involved Region or Country
section and Service Procedure, added a Parts Information section and updated the
Description under Warranty Information.
