NHTSA ID Number: 10162145
Manufacturer Communication Number: PIP5536A
Summary
This Preliminary information communicates There is a PQC parts restriction for the air brakes system on the LCF 6500. If it is found that part or parts are needed that is on restriction, The Dealer will need to call PQC to get the part released.
1 Affected Product
Vehicle
| MAKE | MODEL | YEAR |
| CHEVROLET | LOW CAB FORWARD 6500 | 2018 |
SEOCONTENT-START
Bulletin No.: PIP5536A
Published date: 06/19/2019
Preliminary Information
PIP5536A 2018 Chevrolet LCF 6500 Medium Duty Truck Air Brake PQC Parts Restriction
Models Brand: Model: Model Years: VIN: Engine: Transmissions:
from to
Chevrolet LCF 6500 2018 All All All All
Involved Region or Country North America
Additional Options (RPO) JE4
Condition PQC Parts restriction on the 2018 Chevrolet LCF 6500 air brakes system.
Cause Air Brake PQC Parts Restriction
Correction:
If your diagnosis has led to replacement of the restricted air brake parts, please contact the Product Quality Center (PQC) by opening a case via Dealer Case Management (DCM) From the DCM home page, click on “New PQC Case” found on the Technical Assistance tab.
Then in Global Connect click on the Support/Chat tab, TAC-PQC Tab, PQC -Parts Restrictions Templates to Download the appropriate PQC -P arts Restrictions Template and save a copy to your computer , You can attach a copy of the template to your PQC Case.
Version History
Version 1
Modified 12/15/2017 – Created on
06/19/2019 – Updated SI information with DCM process
SEOCONTENT-END
Bulletin No.: PIP5536A
Published date: 06/19/2019
https://www.nhtsa.gov/recalls?nhtsaId=10162145
https://static.nhtsa.gov/odi/tsbs/2019/MC-10162145-9999.pdf
