NHTSA ID Number: 10118925
Manufacturer Communication Number: 16-NA-156
Summary
This informational bulletin provides information on what vehicles need what model HMI modules due to some of the build differences in the vehicles.
3 Affected Products
Vehicles
| MAKE | MODEL | YEAR |
| CHEVROLET | SILVERADO 2500 | 2016 |
| GMC | SIERRA 2500 | 2016 |
| GMC | SIERRA DENALI | 2016 |
SEOCONTENT-START
Bulletin No.: 16-NA-156
Date: September, 2016
| Subject: | Information on Replacement HMI Modules for Vehicles Built Without Apple CarPlay and Android Auto |
| Brand: | Model: | Model Year: | VIN: | Engine: | Transmission: | ||
|---|---|---|---|---|---|---|---|
| from | to | from | to | ||||
| Chevrolet | Silverado | 2016 | 2016 | GF217012 (Plant F*)
GZ314336 (Plant Z*) GG336479 (Plant G*) |
EOP | All | All |
| GMC | Sierra | 2016 | 2016 | All | All | ||
| *For Build Plant Information See 11th Position of VIN | |||||||
| Involved Region or Country | North America, Middle East and Israel |
| Additional Options (RPO) | Equipped with IO5 Radio and RPO CPO |
Due to supply issues, it is necessary to build a certain quantity of 2016 Silverado and GMC Sierra 1500 and HD trucks without Apple CarPlay and Android Auto compatibility.
The affected trucks will be built with the 2.0 HMI module, which was previously used on 2015 Silverado and Sierra 1500 and HD trucks.
If for any reason the dealer needs to replace the HMI, it needs to be replaced with the correct HMI 2.0 part.
The five ways in which you can identify the affected trucks:
- The window label will display a line in the optional equipment section indicating that a credit of $200 ($225 in Canada) has been applied for the deletion of Apple CarPlay and Android Auto compatibility.
- The Vehicle Invoice will contain the RPO code “CPO” (letter O) and the $200 ($225 in Canada) credit.
| (1) | Chevrolet |
| (2) | GMC |
- The main menu screen of the radio will not have the “projection” icon.
- The Service Parts Identification (SPID) label in the glove box will contain the RPO code “CPO” in addition to the RPO code IO5.
- The RPO list in Warranty History (IVH) will also show “CPO” since it is part of the as built RPO string.
| Version | 3 |
| Modified | May 31, 2016 – Added breakpoints per build plant. Sept 20, 2016 − Added Middle East and Israel to Involved Region or Country. |
SEOCONTENT-END
Bulletin No.: 16-NA-156
Date: September, 2016
https://www.nhtsa.gov/recalls?nhtsaId=10118925
https://static.nhtsa.gov/odi/tsbs/2016/MC-10118925-9999.pdf
To View or Download this Document Click Here
Loading...
Reload document
Open in new tab
16-NA-156
June, 2016
https://www.nhtsa.gov/recalls?nhtsaId=10081866
https://static.nhtsa.gov/odi/tsbs/2016/SB-10081866-2280.pdf
