NHTSA ID Number: 10201114
Manufacturer Communication Number: 15-NA-078
Summary
Front Tire Front Air Deflector Fastener Length Differences
1 Affected Product
Vehicle
| MAKE | MODEL | YEAR |
| CHEVROLET | VOLT | 2016 |
Condition
When performing a PDI, or if removing the left front tire front air deflector or the front bumper fascia center air deflector, the incorrect length screw may have been provided for installation.
If a longer screw is installed in the incorrect position of the left front tire front air deflector, the longer screw may come in contact with the battery coolant hose.
Correction
During replacement/removal of the left front tire front air deflector (2), use shorter screw (Part Number 11570498) instead of the possible provided longer screw in the location pictured above.
Note: The shorter screw is only needed to be used in replacement of the longer screw on the left side of the vehicle.
Parts Information
| Description | Part Number | Qty |
| Screw Asm | 11570498  |
1 |
SEOCONTENT-START
Bulletin No.: 15-NA-078 Date: Dec-2015 Subject: Front Tire Front Air Deflector Fastener Length Differences Brand: Model: Model Year: VIN: Engine: Transmission: from to from to Chevrolet Volt 2016 2016 All All Condition When performing a PDI, or if removing the left front tire front air deflector or the front bumper fascia center air deflector, the incorrect length screw may have been provided for installation. If a longer screw is installed in the incorrect position of the left front tire front air deflector, the longer screw may come in contact with the battery coolant hose. Correction 1 During PDI installation or replacement/removal of the left front tire front air deflector (2), use shorter screw (Part Number 11570498) instead of the possible provided longer screw in the location pictured above. Note: The shorter screw is only needed to be used in replacement of the longer screw on the left side of the vehicle. Parts Information Description Part Number Qty Screw Asm 11570498 1 Warranty Information For vehicles repaired under the Bumper-to-Bumper coverage (Canada Base Warranty coverage), use the following labor operation. Reference the Applicable Warranties section of Investigate Vehicle History (IVH) for coverage information. Labor Operation Description Labor Time 1480618* Left Front Tire Front Air Deflector Screw Installation/Replacement 0.0 hr *This is a unique Labor Operation for Bulletin use to cover part cost only. The required labor is included in 0590072 for the Pre-Delivery Inspection (PDI) or the repair that required the removal of the left front tire deflector. Version 1 Modified
SEOCONTENT-END
1 Associated Document
Manufacturer Communications
Bulletin No.: 15-NA-078
Date: Dec-2015
https://www.nhtsa.gov/recalls?nhtsaId=10201114
MC-10201114-9999.pdf 251.869KB
