NHTSA ID Number: 10201109
Manufacturer Communication Number: 15-NA-068
Summary
Front Lower Ball Joint and Knuckle Inspect ion After Road Hazard Tire/Wheel Damage and/or Noise from Front End
3 Affected Products
Vehicle
MAKE | MODEL | YEAR |
CHEVROLET | CORVETTE | 2014-2016 |
Condition
Some customers may comment on a ticking/clicking/metallic grinding noise heard from front suspension area or lash in steering wheel after a severe road or track front suspension impact.
Cause
This condition may be due to damage on the lower ball joint to steering knuckle connection.
Correction
The front steering knuckle and lower ball joint need to be inspected following the procedure below.
Parts Information
Description | Part Number | Qty |
NUT | 11546368 | 1 (As Required) |
KNUCKLE-STRG (LH) | 84036208 | 1 (As Required) |
KNUCKLE-STRG (RH) | 84036209 | 1 (As Required) |
ARM ASM-FRT LWR CONT (LH) | 23490421 | 1 (As Required) |
ARM ASM-FRT LWR CONT (RH) | 23490422 | 1 (As Required) |
SEOCONTENT-START
Bulletin No.: 15-NA-068 Date: Dec-2015 Subject: Front Lower Ball Joint and Knuckle Inspection After Road Hazard Tire/Wheel Damage and/or Noise from Front End Attention: This Bulletin also applies to any of the models that may be Export vehicles. Brand: Model: Model Year: VIN: Engine: Transmission: from to from to Chevrolet Corvette 2014 2016 All All Condition Some customers may comment on a ticking/clicking/metallic grinding noise heard from front suspension area or lash in steering wheel after a severe road or track front suspension impact. Cause This condition may be due to damage on the lower ball joint to steering knuckle connection. Correction The front steering knuckle and lower ball joint need to be inspected following the procedure below. Service Procedure: 1. Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle in SI. 2. Starting on left front, grab the wheel and tire at the top and bottom, pushing on one side and pulling on the opposite side to manually test the tire/wheel for lateral movement. Note: There should be NO perceived movement. 3. Complete the same lateral movement test on the right front wheel and tire. Note: The right side should also display NO perceived movement and should mimic the left side. • If NO discernible lateral movement is noted, continue to step #4 and inspect the knuckle/lower control arm joint interface. • If discernible lateral movement IS noted, jump ahead to the Lower Control Arm and Steering Knuckle Replacement procedure in SI. 4. Inspect the knuckle to lower control arm joint interface, following the steps below: 4.1. Remove the appropriate front tire and wheel assembly. Refer to Tire and Wheel Removal and Installation in SI. 4.2. Support the lower control arm with a suitable jack stand. 4.3. Loosen the lower ball joint nut at the knuckle. The lower control arm should separate from the knuckle. Note: If the link does not automatically separate from the knuckle, use Special Tool CH-42188-B separator. Note: If Special Tool CH-42188-B separator alone fails to separate the joint, the use of an impact device may be required on the surface of the boss while under load from the separator tool. If this method is used and the knuckle boss is damaged in the process of separating, jump ahead to the Lower Control Arm and Steering Knuckle Replacement procedure in SI. 1 4.4. Remove and discard the lower ball joint nut. 4.5. Clean the upper and lower boss surfaces with an approved parts cleaner and rag. 4.6. Start by visually inspecting the tapered-hole edges on both top and bottom surfaces of the lower boss of the knuckle, looking for evidence of oblong wear/damage. 4.7. Next, visually inspect the knuckle’s machined lower boss face, looking for evidence of material yielding. Yielding will manifest itself visually on this surface as a “bubbling” condition. Note: The surface will likely show a uniform pattern of machining marks across the entire face, which should NOT be confused with the “bubbling” condition. 2 4.8. Finally, using a straight edge, check the flatness of the lower boss surface. Check for flatness across the boss in at least 5-6 different angular positions about the centerline of the hole. Look for light passing between the straight edge and boss surface to indicate a FAILED straight edge test. • If the knuckle shows NO evidence of hole elongation, “bubbling” from yielding, or a failed straight edge test, as indicated throughout step 4 above, continue on to step #5 of this inspection procedure. • If the knuckle DOES show evidence of hole elongation, “bubbling” from yielding, or a failed straight edge test, it will be necessary to replace the lower control arm and knuckle. Jump ahead to the Lower Control Arm and Steering Knuckle Replacement procedure in SI. 5. Re-seat the ball stud into the tapered hole. 6. Install the NEW lower ball joint nut. Tighten: • First Pass, 50 Y (37 lb ft) • Final Pass, plus 120°-135° degrees 7. Reinstall the tire and wheel assembly. Refer to Tire and Wheel Removal and Installation in SI. Parts Information Description Part Number Qty NUT 11546368 1 (As Required) KNUCKLE-STRG (LH) 84036208 1 (As Required) KNUCKLE-STRG (RH) 84036209 1 (As Required) ARM ASM-FRT LWR CONT (LH) 23490421 1 (As Required) ARM ASM-FRT LWR CONT (RH) 23490422 1 (As Required) Warranty Information Labor and the reconfiguration fee associated with these procedures should NOT be charged under warranty. Rather, this should be customer pay. If one of the above parts gets damaged while performing the steps related to the inspection, warranty for part replacement will be covered by GM. Version 2 3 Modified December 1, 2015 – adding step 4.2 under the Service Procedure.
SEOCONTENT-END
1 Associated Document
Manufacturer Communications
Bulletin No.: 15-NA-068
Date: Dec-2015
https://www.nhtsa.gov/recalls?nhtsaId=10201109
MC-10201109-9999.pdf 583.231KB
NHTSA ID Number: 10074305
Manufacturer Communication Number: 15-NA-068
Summary
Front Lower Ball Joint and Knuckle Inspection After Road Hazard Tire/Wheel Damage and/or Noise from
Front End
Some customers may comment on a ticking/clicking/metallic grinding noise heard from front suspension
area or lash in steering wheel after a severe road or track front suspension impact.
This condition may be due to damage on the lower ball joint to steering knuckle connection.
1 Associated Document
Service Bulletin Document
Bulletin No.: 15-NA-068
Date: December, 2015
https://www.nhtsa.gov/recalls?nhtsaId=10074305
SB-10074305-0699.pdf 569.687KB
