NHTSA ID Number: 10070826
Manufacturer Communication Number: PI0432D
Summary
This preliminary informational bulletin provides information regarding a shorter front bumper fascia air deflector available if a customer chooses to purchase one.
4 Affected Products
Vehicle
MAKE | MODEL | YEAR |
CHEVROLET | VOLT | 2011-2014 |
Parts
Description | Qty | Part Number |
Deflector, Front Bumper Fascia Air | 1 | 20993998 |
SEOCONTENT-START
Bulletin No.: PI0432D
Date: September, 2013
Subject: | Shorter Front Bumper Fascia Air Deflector Available for Service |
Models: | 2011-2015 Chevrolet Volt |
This PI has been revised to add the 2014 model year. Please discard PI0432C.
Condition/Concern
Some customers may comment about the low ground clearance of the front bumper fascia air deflector. The air
deflector contacts the ground, scraping at short inclines, because there is not enough clearance between the ground and the front bumper fascia air deflector on an inclined surface.
Recommendation/Instructions
A shorter front bumper fascia air deflector is available for service. Customers have the option to install the front bumper fascia air deflector, which has a higher clearance. The current clearance is 95 mm (3.7 in), the shorter front bumper fascia air deflector brings the clearance up to 125 mm (4.9 in).
- The two screws shown above are pre-installed at the plant and need to be removed from the wheelhouse liner prior to air deflector installation. Reinstall these screws first when installing the air deflector.
- The air deflector (2) needs to be fully seated into the “C” channel on the lower fascia (1) as part of the assembly. Insertion into the “C” channel is a tight fit.
- Prior to installing the screws, line up all three pieces of the air dam to the fascia first.
Important: When installing the screws, verify all holes line up and that the screw catches the retaining nut.
- Working from the center section of the assembly helps eliminate any possible bowing when installing the remaining screws.
Important: The “C” channel must be fully inserted to ensure a quality fit.
Parts Information
Part Number | Description | Qty |
20993998 | Deflector, Front Bumper Fascia Air | 1 |
Effective October 22, 2012, Customer Care and Aftersales will no longer stock the longer air deflector. If the customer insists on a longer deflector (P/N 22751435), please call SPAC for part assistance.
Warranty Information
Please advise the customer that the above change is considered to be a customer option and should be performed at the customer’s expense.
If this change was performed under warranty for customer enthusiasm, it must be submitted as required. A Customer Enthusiasm repair is performed when the failure is determined not to be a defect in material and workmanship, but the Service Agent would like to cover the repair because of customer loyalty. Normally these repairs would be the owner’s responsibility, but GM has decided to participate in the repair to create customer enthusiasm. In these instances, when the transaction is being submitted, Service Agents should select the “Customer Enthusiasm” check box. This warranty repair must be very well documented by service management in the Complaint, Cause and Correction fields.
