NHTSA ID Number: 10134542
Manufacturer Communication Number: 08-08-49-006D
Summary
This technical bulletin provides a procedure to align the inner ashtray/bin pivot pins to correct a customer concern that the front floor console rear ashtray/bin door may not close caused by to the rear ashtray/bin door becoming disengaged from the rear floor console housing tracks.
2 Affected Products
Vehicle
| MAKE | MODEL | YEAR |
| CADILLAC | CTS | 2012-2013 |
Condition
The front floor console rear ashtray/bin door may not close.
Cause
This condition may be caused by the rear ashtray/bin door becoming disengaged from the rear floor console housing tracks.
1 Associated Document
Manufacturer Communications
Bulletin No.: 08-08-49-006D
Date: May, 2016
https://www.nhtsa.gov/recalls?nhtsaId=10134542
MC-10134542-9999.pdf 1555.145KB
