NHTSA ID Number: 10163669
Manufacturer Communication Number: PIC6064B
Summary
This Preliminary Information communication provides information to the technician about vehicles that may have Outside Rearview Mirror Charge Indicator LED may be intermittently inoperative. Technician will need to gain access to the Outside Rearview Mirror Charge Indicator LED Lens assembly and the harness connector and check for a poor connection. Also check the bar code label if the mirror was built prior to June 2014 the Outside Rearview Mirror Charge Indicator LED Lens assembly will need to be replaced.
3 Affected Products
Vehicle
| MAKE | MODEL | YEAR |
CADILLAC | ELR | 2014-2016 |
Condition / Concern
Outside Rearview Mirror Charge Status Indicator LED lamps may be intermittently inoperative on either side of the vehicle.
1 Associated Document
Manufacturer Communications
Bulletin No.: PIC6064B
Published date: 07/19/2019
MC-10163669-9999.pdf 326.181KB
Loading...
Reload document
Open in new tab
NHTSA ID Number: 10127250
Manufacturer Communication Number: PIC6064A
Summary
This Preliminary Information communication advises the technician to check the outside rearview mirror charge indicator harness connector if the charge indicator is intermittently inoperative. The terminals coming out of the outside rearview mirror charge indicator may not extend out far enough to make full contact with the female connector from the harness. There is a date label on the charge indicator that should be checked. If the date sticker on the back of the outside rearview mirror charge status indicator is earlier than June of 2014 it should be replaced.
1 Associated Document
Manufacturer Communications
Bulletin No.: PIC6064A
Date: Sep-2015
Loading...
NHTSA ID Number: 10114436
Manufacturer Communication Number: PIC6064
Summary
This Preliminary Information communication provides information to the technician about vehicles that may have Outside Rearview Mirror Charge Indicator LED may be intermittently inoperative. Technician will need to gain access to the Outside Rearview Mirror Charge Indicator LED Lens assembly and the harness connector and check for a poor connection. Also check the bar code label if the mirror was built prior to June 2014 the Outside Rearview Mirror Charge Indicator LED Lens assembly will need to be replaced.
1 Associated Document
Manufacturer Communications
Bulletin No.: PIC6064
Date: Feb-2015
MC-10114436-9999.pdf 146.178KB
Loading...
| “This site contains affiliate links for which OEMDTC may be compensated” |
- Country of origin : Taiwan
- Model Number : DN100
- Package Weight : 1 pounds
- Package Dimensions : 12" L x 6" W x 4" H
- Helps maximize rear visibility
- Some GM Genuine Parts may have formerly appeared as ACDelco GM Original Equipment (OE)
- GM Genuine Parts are designed, engineered and tested to rigorous standards, and are backed by General Motors
- GM Engineers design and validate OE parts specifically for your Chevrolet, Buick, GMC, or Cadillac vehicle
- GM regularly updates production and service part designs to integrate new materials and technologies
- Rear View Mirror Compatible With TOYOTA 2007-2016 Corolla, 2006-2017 Camry, 2009-2018 RAV4. JEEP 1972-1986 CJ5, CJ6, CJ7, CJ8 Scrambler, 1987-1995 Wrangler YJ, 1997-2002 Wrangler TJ, 2007-2012 Wrangler JK/JKU, 2007-2017 Wrangler, 2018-2020 Wrangler JL, 2007-2016 Compass, 2011-2017 Patriot.
- NISSAN 2003-2019 Rogue, Murano, Kicks, Sentra, Altima, Armada Vehicles. FORD 2006-2017 Focus, 2003-2017 Mondeo.
- 【EXCELLENT FUNCTION】High Quality Materials, Rear View Mirror Must Take 100% Inspected And Tested Multiple Times Before The Shipment, Rear View Mirror Is Constructed Of Premium Material For Long Lasting Durability And Reliability. Direct Replacement, Easy Installation.
- 【Superiority】Easy Installation. High Reliability. It Could Correctly Replace The Vehicles.
- 【Anti-glare function】Anti-glare Rear View mirror It can reduce the glare caused by other vehicle lights at night.Turn on the anti-glare function to reduce traffic accidents and improve driving safety.
- Helps maximize rear visibility
- Some GM Genuine Parts may have formerly appeared as ACDelco GM Original Equipment (OE)
- GM Genuine Parts are designed, engineered and tested to rigorous standards, and are backed by General Motors
- GM Engineers design and validate OE parts specifically for your Chevrolet, Buick, GMC, or Cadillac vehicle
- GM regularly updates production and service part designs to integrate new materials and technologies
- 【BUY NOTE】Check the vehicles modle and year to confirm the compatibility before purchase.
- 【Compatible With Mazda】Rearview mirror compatible with Mazda 2004-2021 Mazda 6, 2016-2023 CX-3, 2006-2017 Mazda 5, 2008-2022 Mazda 3, 2013-2020, CX-5 2007-2022 Mazda 2, 2011-2020 MX-5, 1996-2022, MX-5 Miata, 2006-2022 MX-5, 2001-2011 Tribute, 2004-2008 RX8, 2007-2013 CX-9, 2007-2012 CX-7
- 【Excellent Qualtiy Interior Mirrors】OEM Factory Production, High Quality Rear View Mirror, is constructed of premium material for long lasting durability and reliability. Rea rview mirror Compatible with Nissan 2006-2018 Sentra, 2004-2015 Titan, 2007-2019 Rogue, 2007-2019 Rogue Sport, 2003-2018 Altima, 2003-2019 Murano, 2017-2020 Kicks, 2008-2018 Armada, 2005-2019 Versa, 2006-2015 March, 2000-2001 Maxima, 2002-2014 Navara Frontier, 2002-2015 Xterra
- 【Compatible With Toyota】Interior Rear view mirror Compatible With Toyota Vehicles :2001-2019 4Runner, 1998-2018 Avalon, 1999-2019 Camry, 2010-2014 Fj Cruiser, 2001-2019 Highlander, 2001-2019 RAV4, 1999-2019 Sienna, 2005-2019 Tacoma, 2000-2006 Tundra, 2009-2016 Venza, 2003-2016 Corolla, 2003-2008 Matrix
- 【OEM Factory Qualtiy】This automotive rear view mirror is an excellent safety feature that can help drivers better see rear of vehicle and reduce the danger posed by blind spots.
- Part number: 8201010F01AC
- Fitment:Replacement for the most of the popular vehicle, such as Chevrolet Ford Toyota Nissan Jeep Honda Subaru Hyundai Kia Mazda Buick and More
- Easy Installation:This mirror Kit is resistant and easy to install
- Material: Our mirror kit is made of solid plastic for durability and long service life
- Note:When you buy this mirror Kit, please check carefully whether it is consistent with your part number
- Slightly larger mirror face than the standard rearview mirror, and adjusts to driver's height - FMV approved
- Perfect fit for all vehicles with standard mirror mount
- Installs effortlessly using only a screw driver
- Average of 40 percent savings over dealer replacement
- Manual thumb switch switches from day to night setting for more comfortable driving
- Helps maximize rear visibility
- For proper installation, locate your nearest GM dealer, independent service center, or body shop
- Precise fit for ease of installation
- Helps maximize rear visibility
- Some GM Genuine Parts may have formerly appeared as ACDelco GM Original Equipment (OE)
- GM Genuine Parts are designed, engineered and tested to rigorous standards, and are backed by General Motors
- GM Engineers design and validate OE parts specifically for your Chevrolet, Buick, GMC, or Cadillac vehicle
- GM regularly updates production and service part designs to integrate new materials and technologies
- Compatible Vehicles:10.6 inch Rear View Mirror, it is universal fit type. Compatible with most popular vehicle, for Wrangler CJ YJ TJ JK JL Compass Cherokee, for Nissan Rogue Altima Sentra Murano Kicks Versa Titan Navara Frontier, for Corolla Camry Tacoma rav4 4runner Tundra Sienna Matrix
- Compatible With:For F150 F250 F350 Focus Fusion Edge Explorer Fiesta, for Forte Optima Sportage Soul, for Civic Accord, for Silverado 1500 2500 3500, for Subaru Forester Outback Imreza Legacy, for Hyundai Santa Fe Elantra Sonata
- High Quality:Rear View Mirror is constructed of premium glass and plastic materials for long lasting durability and reliability. We select high quality materials to ensure that the interior rearview mirror meet your expectation
- Anti Glare Function:Anti glare rearview mirrors can reduce glare caused by other vehicle lights at night. Enabling the anti glare function can reduce traffic accidents and improve driving safety
- Easy Installation:Easy to install, you can directly replace the broken or shabby one, without instruction manual. The rear view mirror is designed for quick and complete installation within a few minutes
Last update on 2025-05-08 / Affiliate links / Images from Amazon Product Advertising API
This product presentation was made with AAWP plugin.
SEOCONTENT-START
Bulletin No.: PIC6064B Published date: 07/19/2019
Preliminary Information
PIC6064B Cadillac ELR (EREV) Outside Rearview Mirror Charge Indicator LED Intermittent Operation
During Charging
Models
Brand: Model: Model Years:
VIN:
from to
Engine: Transmissions:
Cadillac ELR 2014 – 2016 All All
All All
Supersession Statement
This PI was superseded to add model year 2016. Please discard PIC6064A.
The following diagnosis might be helpful if the vehicle exhibits the symptom(s) described in this PI.
Condition / Concern
A customer may comment that the Outside Rearview Mirror Charge Status Indicator LED lamps may be intermittently inoperative on either side of the vehicle.
Recommendations / Instructions
This concern may be difficult to duplicate and there may not be any DTCs stored.
Check for a poor connection between the terminals at the Outside Rearview Mirror Charge Indicator LED Lens assembly and the harness connector. The terminals on the circuit board located inside the Lens may not extend outward far enough to engage and make proper contact with the female terminals in the harness connector when the connector is locked into position.
The mirror assembly may have been replaced on a prior date. Do not use the vehicle build date to determine the sticker date on the lens assembly. The date code located on the sticker that is mounted on the back side of the Outside Rearview Mirror Charge
Status Indicator LED Lens assembly must be checked.
If the date on the sticker adhered to the backside of the Outside Rearview Mirror
Charge Status Indicator LED Lens assembly is earlier than June of 2014, the Outside Rearview Mirror Charge Indicator LED Lens assembly will need to be replaced.
Warranty Information
For vehicles repaired under th e EV coverage, use the following labor operation. Reference the Applicable Warranties section of Investigate Vehicle History (IVH) for coverage information.
Labor Operation Description
Labor Time
2041160 Outside Rearview Mirror Turn Signal
Lamp Replacement
0.3
Diagnosis Time To perform electrical diagnosis. 0.3
Please follow this diagnostic or repair process thoroughly and complete each step. If the condition exhibited is resolved without completing every step, the remaining steps do not need to be performed.
