Rear of Headliner Sagging, Rear Edge Visible Through Rear Window – 2016-2019 Chevrolet Camaro

SEOCONTENT-START

Service Bulletin Bulletin No.: 19-NA-174
Date: August, 2019
TECHNICAL
Subject: Rear of Headliner Sagging, Rear Edge Visible Through Rear Window
Brand: Model:
Model Year: VIN:
Engine: Transmission:
from to from to
Chevrolet Camaro
(Coupe only) 2016 2019 All All
Involved Region or Country North America, Europe, Russia, Middle East, Israel, South America, South Korea, China,
Japan, Thailand
Additional Options (RPOs) Coupe Model only.
Condition Some customers may comment on the headliner sagging, and the rear edge of the
headliner is visible through the rear window.
Cause There may be various causes for this condition.
Correction Following the steps in the Service Procedure below, add magnets to the rear of the
headliner.
Service Procedure
1. It is only necessary to lower the rear of the
headliner. Only do those steps in the headlining
procedure that will allow access to the roof sheet
metal and top side of headliner. Refer to the
appropriate Headlining Trim Panel Replacement
in SI.
2. Order two of the magnet service parts listed in the
part table below and hot glue the magnets to the
headliner following the steps below:
2.1. Fold the rear seat back to the full downward
position.
Note: Because this will be a mostly blind operation,
applying tape on the topside of the headliner, to mark
the location of the magnet installation, will be helpful.
5381469
2.2. Position the tape edges at the locations
dimensioned off of the rear crossmember in
the graphic above. 153 mm (6.0 in) (1)
inboard of the CENTER hole location and 51
mm (2.0 in) (2) from the rear edge of the
crossmember.
Page 2 August, 2019 Bulletin No.: 19-NA-174
2.3. To minimize risk of any glue dripping on
interior trim, cover any exposed trim with an
appropriate covering.
Tip: It may be helpful to have a 2nd person apply the
hot glue to the magnet and hand it to the installer
through the trunk/rear seat opening.
2.4. Apply the hot glue to each magnet, then press
the magnets to the headliner at both tape
edge mark locations.
2.5. Allow the glue to cure for a few minutes
before repositioning the headliner and
securing the magnets to the roof sheet metal.
3. Reinstall the headliner and any trim removed.
Refer to the appropriate Headlining Trim Panel
Replacement in SI.
4. Reposition the rear seat back.
Parts Information
Causal
Part
Description Part
Number
Qty
N/A MAGNETASMHDLNG
T/PNL
84717479 2
Warranty Information
For vehicles repaired under the Bumper-to-Bumper
coverage (Canada Base Warranty coverage), use the
following labor operation. Reference the Applicable
Warranties section of Investigate Vehicle History (IVH)
for coverage information.
Labor
Operation
Description Labor Time
1086078* Rear Headliner Sag – Install
Magnets
0.7 hr
*This is a unique Labor Operation for Bulletin use only.
Version 1
Modified Released July 31, 2019
