NHTSA ID Number: 10201279
Manufacturer Communication Number: PIT5689D
Summary
This Preliminary information communicates that some customers may comment that after an auto-stop event the engine does not restart and to inspect the engine ground strap. Temporarily on hold while PIE0572 is active. PIE0572 has now ended and reinstating the PI.
Condition
Some customers may comment of the following:
– After an auto-stop event the engine does not restart (if equipped).
– No crank (may be intermittent)
– Dead Battery
– SES MIL with any of the following DTCs: P0562, P0617, P0621 P0622, P0700, P1005, P26E6, P305D, P305E, P2796, U010E, U0102, U0106, U0284, U0285, U0672, U029D, U029E, U02A1, U02A3, U0623, U111A, U111E, U1348, U18DE
Cause
These concerns could be caused by a broken or loose engine ground cable/strap, which grounds the engine to the body.
Correction:
Inspect the engine to body ground cable/strap, G132 and G134.
SEOCONTENT-START
Bulletin No.: PIT5689D Published date: 06/10/2021 Preliminary Information PIT5689D No Restart after an Auto Stop Event / No Crank / Dead Battery / DTC P0562 P0617 P0621 P0622 P0700 P1005 P26E6 P305D P305E P2796 U010E U0102 U0106 U0284 U0285 U0672 U029D U029E U02A1 U02A3 U0623 U111A U111E U1348 U18DE Product Investigation Review Required Models Brand: Chevrolet Chevrolet GMC GMC Model: Silverado 1500 (New Model) Silverado Sierra 1500 (New Model) Sierra Model Years: 2019 2020 – 2021 2019 2020 – 2021 VIN: from to All All All All All All All All Engine: All All All All Transmissions: All All All All Involved Region or Country North America Condition Some customers may comment of the following: – After an auto-stop event the engine does not restart (if equipped). – No crank (may be intermittent) – Dead Battery – SES MIL with any of the following DTCs: P0562, P0617, P0621 P0622, P0700, P1005, P26E6, P305D, P305E, P2796, U010E, U0102, U0106, U0284, U0285, U0672, U029D, U029E, U02A1, U02A3, U0623, U111A, U111E, U1348, U18DE Cause These concerns could be caused by a broken or loose engine ground cable/strap, which grounds the engine (2) to the body (1), as shown below. 1 – G132 2 – G134 Shown above is ground G132 loose. Correction: Inspect the engine to body ground cable/strap, G132 and G134. Tighten any loose ground connections or replace any damaged ground cable/strap. Ensure that the ground cable/strap is properly orientated to prevent damage to the ground cable/strap caused by powertrain movement. Warranty Information For vehicles repaired under the Bumper-to-Bumper coverage (Canada Base Warranty coverage), use the following labor operation. Reference the Applicable Warranties section of Investigate Vehicle History (IVH) for coverage information. Labor Operation 4042010 Description Battery Negative Cable Extension Cable Strap Replacement Labor Time Use Published Time Version History Version 5 06/04/2019 – Created on 11/22/2019 – superseded to update the title, condition and correction. Modified 06/22/2020 – Updated to temporarily refer to PIE0572 for this condition. 02/19/2021 – Updated to Title, Condition, Cause and Correction. 06/10/2021 – Updates to the Warranty Section
SEOCONTENT-END
6 Affected Products
Vehicles
| MAKE | MODEL | YEAR |
| CHEVROLET | SILVERADO 1500 | 2019, 2021 |
| CHEVROLET | SILVERADO 2500 | 2020 |
| GMC | SIERRA 1500 | 2019, 2021 |
| GMC | SIERRA 2500 | 2020 |
1 Associated Document
Manufacturer Communications
Bulletin No.: PIT5689D
Published date: 06/10/2021
MC-10201279-9999.pdf 566.837KB
Loading...
Reload document
Open in new tab
NHTSA ID Number: 10162111
Manufacturer Communication Number: PIT5689
Summary
This Preliminary information communicates that some customers may comment that after an auto-stop event the engine does not restart and to inspect the engine ground strap.
1 Associated Document
Manufacturer Communications
Bulletin No.: PIT5689
Published date: 06/4/2019
MC-10162111-9999.pdf 729.966KB
